Torque Specifications
| Description | Part Number | Torque |
|---|---|---|
| Engine appearance cover mounting stud | 6A957 | 5 Nm (44 lb-in) |
| Ignition coil-on-plug bolts | W500301 | 8 Nm (71 lb-in) |
| Ignition coil-on-plug stud bolts | W715638 | 8 Nm (71 lb-in) |
| Spark plugs | CYFS -12Y-2 | 12 Nm (106 lb-in) |
TORQUE SPECIFICATIONS
General Specifications
| Item | Specification |
|---|---|
| Spark plug | CYFS -12Y-2 |
| Spark plug gap | 0.7 mm (0.028 in) - 0.8 mm (0.031 in) |
GENERAL SPECIFICATIONS
Scheme 1
| Item | Engineering Part Number | Description | Torque | Material Name | Notes |
|---|---|---|---|---|---|
| 1 | Part of 12C508 | Wire harness retainer (2 required) | |||
| 2 | 9G271 | EVAP canister purge valve | |||
| 3 | 6A957 | Engine appearance cover mounting stud | 5 Nm (44 lb-in) | ||
| 4 | W500301 | Ignition coil-on-plug bolt (2 required) | 8 Nm (71 lb-in) | ||
| 5 | W715638 | Ignition coil-on-plug stud bolt (2 required) | 8 Nm (71 lb-in) | ||
| 6 | 12A366 | Ignition coil-on-plug (4 required) | Silicone Brake Caliper Grease and Dielectric Compound | ||
| 7 | 12A402 (part of 12A366) | Ignition coil-on-plug rubber boot assembly (4 required) | |||
| 8 | 12405 | Spark plug (4 required) | 12 Nm (106 lb-in) | ||
| 9 | Part of 12C508 | Ignition coil-on-plug electrical connector (4 required) |
