Fuel System - General Information: Other Ford Explorer V

FP Shut-off Feature

In the event of a moderate to severe collision, the vehicle is equipped with a FP shut-off feature that is initiated by the event notification signal.

Should the vehicle shut off after a collision due to this feature, the vehicle may be restarted by first turning the ignition to the OFF position and then turning the ignition to the ON position. In some instances the vehicle may not start the first time and may take one additional ignition cycle.

General Procedure

1. NOTE: The FP relay is located in the BJB, location F15. Remove the FP relay.
2. NOTE: The engine will crank and not start. Crank the engine for approximately 20 seconds.
3. Crank the engine an additional 20 seconds to make sure the fuel system pressure has been released.
4. Turn the ignition switch to the OFF position.
5. When fuel system service is complete, install the FP relay.
6. NOTE: It may take more than one key cycle to pressurize the fuel system. Cycle the ignition key and wait 3 seconds to pressurize the fuel system. Check for leaks prior to starting the engine.
7. Start the vehicle and check the fuel system for leaks.

Scheme 5

1. Release the fuel system pressure. REFER to «Fuel System Pressure Release»(ref-517564-S07897741922012121200000) .
2. Disconnect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .
3. Disconnect the fuel tube-to-fuel jumper tube quick connect coupling. REFER to «Quick Connect Coupling»(ref-517564-S07557795332012121200000) .
4. Install the Fuel Pressure Test Adapter and the Fuel Pressure Test Kit between the fuel tube and the fuel jumper tube.
5. NOTE: The FP relay was previously removed to release the fuel system pressure and must be installed to test the fuel system pressure. Install the FP relay.
6. Connect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .
7. NOTE: Carry out a ignition ON engine OFF visual inspection for fuel leaks prior to completing the fuel system pressure test. NOTE: After completing the fuel system pressure test, open the drain valve on the Fuel Pressure Test Kit and release any residual fuel into a suitable container prior to removing the tool. Test the fuel system pressure to make sure it is within the specified range. REFER to «General Specifications»(ref-517564-S24371574322012121200000) .

Scheme 6

Scheme 7

Scheme 8

1. Disconnect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .
2. NOTE: The supplement refueling adapter is located in the luggage compartment. Install the supplemental refueling adapter and a length of semi-rigid fuel drain tube into the Easy Fuel ™ (capless) fuel tank filler pipe.
3. Attach the Fuel Storage Tanker to the fuel drain tube and drain as much fuel as possible from the Easy Fuel ™ (capless) fuel tank filler pipe, lowering the fuel level below the fuel tank inlet spout.
4. NOTE: Some residual fuel may remain in the fuel tank filler pipe. Carefully drain into a suitable container. Release the clamp and remove the fuel tank filler pipe hose from the fuel tank.
5. Insert the fuel drain tube into the fuel tank inlet spout, attach the Fuel Storage Tanker and drain as much fuel as possible from the fuel tank.

Disconnect - Type 1

Note. When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube or damage to the tube or connector retaining clip can occur.

Note. Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is essential that absolute cleanliness is observed when working with these components or component damage can occur. Always install plugs to any open orifices or tubes.

Note. Do not use any tools. The use of tools may cause a deformity in the clip components which may cause fuel leaks.

Scheme 9

Scheme 10

1. If servicing a liquid fuel tube quick connect coupling, release the fuel system pressure. REFER to «Fuel System Pressure Release»(ref-517564-S07897741922012121200000) .
2. Disconnect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .
3. NOTE: When reusing liquid or vapor tube quick connect couplings, make sure to use compressed air to remove any foreign material from the retaining clip area before disconnecting from the tube. Separate the tabs of the retainer clip and pull it to the outward position in the quick connect coupling.
4. Depress the retainer clip and disconnect the quick connect coupling from the tube.

Scheme 11

Scheme 12

1. Inspect and clean both quick coupling ends.
2. Install the quick connect coupling onto the tube.
3. NOTE: Make sure the retainer clip is fully seated and locked onto the tube by pulling on the quick connect coupling. Press the retainer clip into the quick connect coupling body until flush and the tabs are locked in place.
4. Connect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .

Disconnect - Type 2

Note. When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube or damage to the tube or connector retaining clip can occur.

Note. Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is essential that absolute cleanliness is observed when working with these components or component damage can occur. Always install plugs to any open orifices or tubes.

Note. Do not use any tools. The use of tools may cause a deformity in the clip components which may cause fuel leaks.

Scheme 13

Scheme 14

1. If servicing a liquid fuel tube quick connect coupling, release the fuel system pressure. REFER to «Fuel System Pressure Release»(ref-517564-S07897741922012121200000) .
2. Disconnect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .
3. NOTE: When reusing liquid or vapor tube quick connect couplings, make sure to use compressed air to remove any foreign material from the retaining clip area before disconnecting from the tube. Squeeze the quick connect coupling retainer locking tabs to release the locking mechanism and push the locking mechanism outward to release the tube.
4. Remove the quick connect coupling from the tube.

Scheme 15

Scheme 16

1. Inspect and clean both quick connect coupling ends.
2. Install the quick connect coupling onto the tube.
3. NOTE: Visually inspect and verify that the locking mechanism is flush with the quick connect coupling housing and that the locking tabs are securely fastened. Depress the quick connect coupling locking mechanism into the locked position.
4. Pull on the quick connect coupling and the tube to make sure it is securely fastened.
5. Connect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .

Disconnect - Type 3

Note. When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube or damage to the tube or connector retaining clip can occur.

Note. Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is essential that absolute cleanliness is observed when working with these components or component damage can occur. Always install plugs to any open orifices or tubes.

Note. Do not use any tools. The use of tools may cause a deformity in the clip components which may cause fuel leaks.

Scheme 17

Scheme 18

1. If servicing a liquid fuel tube quick connect coupling, release the fuel system pressure. REFER to «Fuel System Pressure Release»(ref-517564-S07897741922012121200000) .
2. Disconnect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .
3. NOTE: When reusing liquid or vapor tube quick connect couplings, make sure to use compressed air to remove any foreign material from the retaining clip area before disconnecting from the tube. Release the lock tab on the quick connect coupling.
4. Separate the quick connect coupling from the fitting.

Scheme 19

Scheme 20

1. Inspect and clean both quick connect coupling ends.
2. Release the lock tab and install the quick connect coupling onto the fitting.
3. Apply the lock tab into the latched position.
4. Pull on the quick connect coupling to make sure it is securely fastened.
5. Connect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .

Disconnect - Type 4

Note. When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube or damage to the tube or connector retaining clip can occur.

Note. Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is essential that absolute cleanliness is observed when working with these components or component damage can occur. Always install plugs to any open orifices or tubes.

Note. Do not use any tools. The use of tools may cause a deformity in the clip components which may cause fuel leaks.

Scheme 21

Scheme 22

1. If servicing a liquid fuel tube quick connect coupling, release the fuel system pressure. REFER to «Fuel System Pressure Release»(ref-517564-S07897741922012121200000) .
2. Disconnect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .
3. NOTE: When reusing liquid or vapor tube quick connect couplings, make sure to use compressed air to remove any foreign material from the retaining clip area before disconnecting from the tube. Squeeze the quick connect coupling retainer locking tabs to release the locking mechanism and push the locking mechanism outward to release the tube.
4. Remove the quick connect coupling from the tube.

Scheme 23

1. Inspect and clean both quick connect coupling ends.
2. Install the quick connect coupling onto the tube.
3. Pull on the quick connect coupling and the tube to make sure it is securely fastened.
4. Connect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .

Disconnect - Type 5

Note. When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube or damage to the tube or connector retaining clip can occur.

Note. Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is essential that absolute cleanliness is observed when working with these components or component damage can occur. Always install plugs to any open orifices or tubes.

Note. Do not use any tools. The use of tools may cause a deformity in the clip components which may cause fuel leaks.

Scheme 24

1. If servicing a liquid fuel tube quick connect coupling, release the fuel system pressure. REFER to «Fuel System Pressure Release»(ref-517564-S07897741922012121200000) .
2. Disconnect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .
3. NOTE: When reusing liquid or vapor tube quick connect couplings, make sure to use compressed air to remove any foreign material from the retaining clip area before disconnecting from the tube. Remove the quick connect coupling from the fitting. Depress the clip into the quick connect coupling. Remove the quick connect coupling from the fitting.

Scheme 25

1. Inspect and clean both quick connect coupling ends.
2. Install the quick connect coupling onto the tube.
3. Pull on the quick connect coupling and the tube to make sure it is securely fastened.
4. Connect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .

Disconnect

Note. When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube or damage to the tube or connector retaining clip can occur.

Note. Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is essential that absolute cleanliness is observed when working with these components or component damage can occur. Always install plugs to any open orifices or tubes.

Scheme 26

Scheme 27

1. If servicing a liquid fuel tube spring lock coupling, release the fuel system pressure. REFER to «Fuel System Pressure Release»(ref-517564-S07897741922012121200000) .
2. Disconnect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .
3. Install the Spring Lock Coupling Disconnect Tool on the tube and push into the spring lock coupling to release.
4. Separate the spring lock coupling from the tube.

Scheme 28

1. Align and push the spring lock coupling onto the tube until fully seated.
2. Pull on the coupling to make sure it is fully engaged.
3. Connect the battery ground cable. REFER to «BATTERY DISCONNECT»(ref-517589-S39248827582012121200000) .
