ALIGNMENT SPECIFICATIONS
| Item | LH | RH | Total/ Split |
|---|---|---|---|
| Front | |||
| Caster | 4.6° ± 0.75° | 4.6° ± 0.75° | 0° ± 0.75° |
| Camber | 0.5° ± 0.75° | 0.5° ± 0.75° | 0° ± 0.75° |
| Toe (positive value is toe-in, negative value is toe-out) | 0.20° ± 0.20° | ||
| Rear | |||
| Camber | 0.5° ± 0.75° | 0.5° ± 0.75° | 0° ± 0.75° |
| Toe (positive value is toe-in, negative value is toe-out) | 0.05° ± 0.20° | 0.05° ± 0.20° | 0.10° ± 0.20° |
ALIGNMENT SPECIFICATIONS
GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Ride Height | |
| Front | 16 mm (0.63 in) ± 8 mm (0.31 in) |
| Rear | 95 mm (3.74 in) ± 10 mm (0.39 in) |
| Vehicle Lean (Side-to-Side Height Differences) | |
| Front - maximum | 7 mm (0.28 in) |
| Rear - maximum | 8 mm (0.32 in) |
| Thrust Angle (Dogtracking) | |
| Thrust Angle - maximum (centerline of front tires compared to centerline of rear tires) | 30 mm (1.18 in) |
| Ball Joint Deflection | |
| Lower | 0-0.8 mm (0-0.032 in) |
| Upper | 0-0.2 mm (0-0.008 in) |
| Tire Balance Weight | |
| Maximum balance weight (total of inner and outer wheel flange) | 170 g (6.0 oz.) |
| Tire Inflation | |
| Tires | See safety certification sticker located on driver door jamb. |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Front upper control arm bolt | 150 |
| Tie-rod jam nut | 70 |
| Lower arm rearward nut | 200 |
| Rear upper arm inboard nut | 250 |
| Toe link inboard nut | 275 |
TORQUE SPECIFICATIONS
The front camber and caster are adjusted by loosening the upper control arm bolts which will allow the upper arm to be moved in the slotted frame holes. The LF caster can be adjusted by loosening the lower control arm rearward nut to allow the lower arm to be moved in the slotted frame hole. Front toe is adjusted by the use of the front wheel spindle tie rods. The rear camber is adjusted by replacing the upper arm inboard flag nut with a non-flag nut to allow the arm to be adjusted in the slotted frame holes. The rear toe is adjusted through the use of the rear toe link cam bolt.
Scheme 13
Camber is the vertical tilt of the wheel when viewed from the front. Camber can be positive or negative and has a direct effect on tire wear.
Scheme 14
| Item | Description |
|---|---|
| 1 | True vertical |
| 2 | Positive caster |
| 3 | Ball joint center line |
| 4 | Pivot center line |
Caster is the deviation from vertical of an imaginary line drawn through the ball joints when viewed from the side. The caster SPECIFICATIONS will give the vehicle the best directional stability characteristics when loaded and driven. The caster setting is not related to tire wear.
Scheme 15
Scheme 16
The vehicle toe setting
- affects tire wear and directional stability.
- must be checked after adding aftermarket equipment, such as a snowplow.
Scheme 17
| Item | Description |
|---|---|
| 1 | Distance between the ground and center of shock absorber lower bolt |
| 2 | Ride height = 3-1 |
| 3 | Distance between the ground and the center of the lower arm inboard bolt |
Scheme 18
| Item | Description |
|---|---|
| 1 | Distance between the ground and center of shock absorber lower bolt |
| 2 | Ride height = 3-1 |
| 3 | Distance between the ground and the center of the lower arm inboard bolt |
Scheme 19
| Item | Description |
|---|---|
| 1 | Vehicle centerline |
| 2 | Axle centerline |
| 3 | Thrust angle |
Thrust angle (also known as dogtracking) is the condition in which the rear axle is not square to the chassis. Heavily crowned roads can give the illusion of incorrect thrust angle.
