GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Lubricants | |
| MERCON® Multi-Purpose Automatic Transmission Fluid XT-2-QDX (US); XT-2-LM12 (Canada) | MERCON® |
| Power Steering Gear | |
| Turning effort | 4.5 kg (10 lb) |
| Tie-rod articulation torque | 1-3 N.m |
| Turns lock-to-lock | 3.70 |
| Power Steering Purge Vacuum | |
| Air purge vacuum | 68-85 kPa (20-25 in-Hg) |
| Power Steering Pump | |
| Flow rate @ 74°-80°C (165°-175°F), engine speed set at 1500 rpm and power steering analyzer set at 345 kPa (50 psi) | 11.4-13.2 liters/minute (2.5-2.9 gpm) |
| Flow rate-minimum @ 74°-80°C (165°-175°F), power steering analyzer set at 5,102 kPa (750 psi) and engine speed set at idle | 4.35 liters/minute (1.15 gpm) |
| Maximum pressure @ 74°-80°C (165°-175°F) and engine speed set at 2,100 rpm | 1,172 kPa (170 psi) |
| Relief pressure | 1,400-1,530 @ 500 rpm |
GENERAL SPECIFICATIONS
The power steering system consists of the
- power steering pump.
- fluid reservoir.
- rack and pinion steering gear.
- fluid cooler.
- high and low pressure steering lines/hoses.
Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Dial Thermometer 0-220°F 023-R0007 or equivalent 100W/12 Volt DC UV Lamp 164-R0751 Vacuum Pump Kit 416-D002 (D95L-7559-A) or equivalent Evacuation Cap, Power Steering 211-265 or equivalent
Scheme 1
Scheme 2
| Item | Specification |
|---|---|
| MERCON® Multi-Purpose Automatic Transmission Fluid XT-2-QDX (US); XT-2-LM12 (Canada) | MERCON® |
| Automatic Transmission/Power Steering Dye 164-R3701 or equivalent |
Material
