Interior Lighting System: Removal & Installation Ford Explorer IV

Interior/illumination Lights 1 illustration

REMOVAL AND INSTALLATION

  1. Open the rear overhead console storage or garage door opener bin to access the retaining screw. Remove the screw.
  2. Pull the front of the overhead console down and remove the console from the console retaining clips. Disconnect the electrical connector(s).
  3. To install, reverse the removal procedure.

Scheme 14

Scheme 14: Interior Lamp - Rear
Scheme 14: Interior Lamp - Rear
ItemPart NumberDescription
113783Rear interior lamp lens
213776Rear interior lamp
3Rear interior lamp electrical connector (part of 14335)
  1. Remove the rear interior lamp lens.
  2. Release the 2 retaining clips (through the access holes) and remove the rear interior lamp assembly. Disconnect the electrical connector.
  3. To install, reverse the removal procedure.
