Engine Ignition System - 4.0L SOHC: Specifications Ford Explorer IV

Ignition System 2 illustrations ~221 words

GENERAL SPECIFICATIONS

ItemSpecification
Base ignition timing10 degrees BTDC Non-adjustable
Firing order1-4-2-5-3-6
Spark plug gap1.32-1.42 mm (0.052-0.056 in)
Spark plug type (LH)AGSF24PM
Spark plug type (RH)AGSF24PGM
Lubricants and Chemicals
Silicone Brake Caliper Grease and Dielectric Compound XG-3-AESE-M1C171-A

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

DescriptionNm
Ignition coil bolts6
Spark plugs17

TORQUE SPECIFICATIONS

The ignition system consists of the following

  1. Crankshaft position (CKP) sensor
  2. Ignition coil
  3. Spark plug wire
  4. Spark plug

The ignition system is

  1. an electronic distributorless ignition system (EDIS).
  2. controlled by an electronic engine control integrated into the powertrain control module (PCM).
  3. set at 10 degrees before top dead center (BTDC) for base timing and is not adjustable.

The crankshaft position (CKP) sensor

  1. is a variable reluctance sensor.
  2. senses a missing tooth on the crankshaft damper pulse ring.
  3. generates a crankshaft position signal which is sent to the PCM. The PCM counts this signal for engine rpm.

The ignition coil

  1. changes low-voltage pulses from the PCM to high-voltage pulses.
  2. fires 2 spark plugs simultaneously.
  3. has 3 transformers. one transformer fires the spark plugs for cylinders 1 and 5 one transformer fires the spark plugs for cylinders 2 and 6 one transformer fires the spark plugs for cylinders 3 and 4

Spark plug wires carry high-voltage pulses from the ignition coil to the spark plugs.

The spark plugs

  1. change high-voltage pulses to spark at the gap, which ignites the fuel and air mixture.

The firing order is: 1-4-2-5-3-6.

Scheme 2

Scheme 2

Refer to the Introduction - Gasoline Engines .

Scheme 3

Scheme 3: Engine Ignition Components - Exploded View
ItemPart NumberDescription
114A464Ignition coil electrical connector
214489Radio noise suppressor electrical connector
312297Spark plug wire retainers
412286Spark plug wire (6 required)
512405Spark plug (6 required)
6W706216-SIgnition coil bolts (4 required)
712029Ignition coil
  1. For additional information, refer to the appropriate procedures.
