Interior lights — Instrument illumination circuit Ford Explorer III
All systems — 29 systems
- Air conditioning 4
- Anti-lock brakes 3
- Anti-theft 2
- Computer data lines
- Cruise control 3
- Defoggers
- Engine performance 4.0l
- Engine performance 4.6l
- Exterior lights 5
- Ground distribution
- Headlights 2
- Horn 3
- Instrument cluster 2
- Interior lights 4
- Memory systems 2
- Navigation
- Power distribution
- Power door locks 3
- Power mirrors 2
- Power seats 6
- Power top/sunroof
- Power windows
- Radio 5
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 4
- Warning systems 3
- Wiper/washer 3
Components on these wiring diagrams 25
Click a component to highlight it on every diagram it appears on.
