ENGINE-4.0L SOHC: Removal & Installation Ford Explorer III

Item 1: Accessory Drive Belt Removal Note

1. Rotate the accessory drive belt tensioner counterclockwise and remove the accessory drive belt. Rotate the accessory drive belt tensioner counterclockwise. Remove the accessory drive belt.

Scheme 98

Scheme 99

Scheme 100

1. With the vehicle in NEUTRAL, position on a hoist.
2. Remove the air cleaner outlet tube. For additional information, refer to «REMOVAL & INSTALLATION»(ref-156578) .
3. To remove individual components, carry out only the listed steps.
4. Illustration 1 of 2. Remove the components in the order indicated in the following illustration and table.
5. Illustration 2 of 2. Remove the components in the order indicated in the following illustration and table.
6. To install, reverse the removal procedure.

Item 13: EGR Valve Gasket Removal Note

1. Carefully clean the EGR sealing surfaces.

Scheme 101

1. Remove the components in the order indicated in the following illustration and table.
2. To install, reverse the removal procedure.

Scheme 102

Scheme 103

Scheme 104

Scheme 105

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY AND CHARGING SYSTEM»(ref-194056) .
2. Remove the air cleaner outlet pipe. For additional information, refer to «REMOVAL & INSTALLATION»(ref-156578) .
3. Illustration 1 of 4. Remove the components in the order indicated in the following illustration and table.
4. Illustration 2 of 4. Remove the components in the order indicated in the following illustration and table.
5. Illustration 3 of 4. Remove the components in the order indicated in the following illustration and table.
6. Illustration 4 of 4. Remove the components in the order indicated in the following illustration and table.

Scheme 106

Scheme 107

Scheme 108

Scheme 109

1. Disconnect the accelerator and the speed control cables from the throttle body.
2. Remove the accelerator cable and the speed control cable from the bracket. Position the cables away from the intake manifold.
3. Disconnect the accelerator cable and the speed control cable routing clips. Disconnect the vacuum hose.
4. Disconnect the spark plug wires.
5. Disconnect the knock sensor (KS) electrical connector retainer.

Item 21: Intake Manifold Gaskets Removal Note

Clean the sealing surfaces, inspect the gaskets and install new gaskets if necessary.

Scheme 110

Scheme 111

Scheme 112

1. Release the fuel system pressure. For additional information, refer to «FUEL SYSTEM»(ref-194052) .
2. Remove the intake manifold. For additional information, refer to «INTAKE MANIFOLD»(ref-194043-S07435760892005092600000) .
3. Illustration 1 of 2. Remove the components in the order indicated in the following illustration and table.
4. Illustration 2 of 2. Remove the components in the order indicated in the following illustration and table. To install, reverse the removal procedure.

Scheme 113

Scheme 114

Scheme 115

Scheme 116

1. Disconnect the fuel injector electrical connectors and routing clips.
2. Install the special tool.
3. Press the special tool into the open end of the cage.
4. Separate the fuel line fitting.

Item 7: Fuel Supply Manifold Removal Note

1. Discard the fuel supply manifold O-ring and install a new O-ring.

Scheme 117

1. Disconnect the retaining clips and position the spark plug wires aside.

Item 11: RH Valve Cover Gasket Removal Note

1. Clean and inspect the sealing surfaces. Install a new gasket, if necessary.

Scheme 118

Scheme 119

1. Remove the intake manifold. For additional information, refer to «INTAKE MANIFOLD»(ref-194043-S07435760892005092600000) .
2. Illustration 1 of 2. Remove the components in the order indicated in the following illustration and table.
3. Illustration 2 of 2. Remove the components in the order indicated in the following illustration and table.
4. To install, reverse the removal procedure.

Scheme 120

1. Detach the pin-type retainer on the wiring harness near the ignition coil electrical connector.
2. Disconnect the fuel injector electrical connectors and the harness standoff clips.

Scheme 121

1. Disconnect the accelerator cable from the routing clip and position it aside.

Scheme 122

1. Disconnect the standoff clips and position the spark plug wires aside.

Item 7: Valve Cover Gasket Removal Note

1. Clean and inspect the sealing surfaces. Install a new gasket, if necessary.

Scheme 123

Scheme 124

Scheme 125

Scheme 126

1. Remove the fan shroud. For additional information, refer to «ENGINE COOLING»(ref-194047) .
2. Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE BELT, TENSIONER AND PULLEY»(ref-194043-S33762287922005092600000) .
3. Remove the components in the order indicated in the following illustration and table.
4. To install, reverse the removal procedure.

Item 1: Crankshaft Pulley Bolt Removal Note

1. Using the special tool, remove and discard the damper bolt.

Scheme 127

1. Using the special tool, remove the crankshaft pulley.

Scheme 128

1. Using the special tool, remove the crankshaft front seal.

Scheme 129

1. Using the special tool, install the crankshaft front seal.

Scheme 130

1. Using the special tool, install the crankshaft pulley

Scheme 131

1. Using the special tool, tighten the bolt in two stages: Stage 1: Tighten the bolt to 45 Nm (33 lb-ft). Stage 2: Tighten the bolt and additional 85 degrees.

Scheme 132

Scheme 133

Scheme 134

Scheme 135

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY AND CHARGING SYSTEM»(ref-194056) .
2. Drain the cooling system. For additional information, refer to «ENGINE COOLING»(ref-194047) .
3. Remove the crankshaft pulley and front oil seal. For additional information, refer to «CRANKSHAFT PULLEY AND CRANKSHAFT SEAL»(ref-194043-S01325457632005092600000) .
4. Remove the components in the order indicated in the following illustration and table. Illustration 1 of 3.
5. Remove the components in the order indicated in the following illustration and table. Illustration 2 of 3.
6. Remove the components in the order indicated in the following illustration and table. Illustration 3 of 3.
7. To install, reverse the removal procedure.
8. Fill and bleed the cooling system. For additional information, refer to «ENGINE COOLING»(ref-194047) .
9. Connect the battery ground cable. For additional information, refer to «BATTERY AND CHARGING SYSTEM»(ref-194056) .

Scheme 136

1. Remove the heater control valve bracket bolt.

Scheme 137

1. Apply silicone gasket and sealant to the oil pan and the engine block mating surfaces.
2. Apply silicone gasket and sealant to the front cover in two places.

Scheme 138

Scheme 139

1. Remove the valve covers. For additional information, refer to «VALVE COVER LH»(ref-194043-S18704149072005092600000) and «VALVE COVER RH»(ref-194043-S41257120272005092600000) .
2. Remove the fuel supply manifold. For additional information, refer to «REMOVAL & INSTALLATION»(ref-156578) .
3. Remove the engine front cover. For additional information, refer to «ENGINE FRONT COVER»(ref-194043-S28375410142005092600000) .
4. Remove the thermostat housing. For additional information, refer to «ENGINE COOLING»(ref-194047) .
5. Remove all of the roller followers. For additional information, refer to «CAMSHAFT ROLLER FOLLOWER AND HYDRAULIC LASH ADJUSTER»(ref-194043-S40561732132005092600000) .
6. Turn the crankshaft clockwise to position the number one cylinder at top dead center.
7. Remove the components in the order indicated in the following illustration and table.
8. To install, reverse the removal procedure.
9. Install the roller followers. For additional information, refer to «CAMSHAFT ROLLER FOLLOWER AND HYDRAULIC LASH ADJUSTER»(ref-194043-S40561732132005092600000) .
10. Install the thermostat housing. For additional information, refer to «ENGINE COOLING»(ref-194047) .
11. Install the engine front cover. For additional information, refer to «ENGINE FRONT COVER»(ref-194043-S28375410142005092600000) .
12. Install the fuel supply manifold. For additional information, refer to «REMOVAL & INSTALLATION»(ref-156578) .
13. Install the valve covers. For additional information, refer to «VALVE COVER RH»(ref-194043-S41257120272005092600000) and «VALVE COVER LH»(ref-194043-S18704149072005092600000) .

Scheme 140

1. Remove the LH camshaft sprocket bolt. Install the special tools to hold the camshaft sprocket. Remove the camshaft sprocket bolt.

Scheme 141

1. Use the special tool to keep the crankshaft from turning while loosening the jackshaft bolt.

Item 9: Timing Chain and Guide Installation Note

1. Install the lower chain sprocket and the camshaft sprocket.

Scheme 142

1. Keep the crankshaft from turning and tighten the jackshaft sprocket bolt in two stages. Stage 1: Tighten the bolt to 45 Nm (33 lb-ft). Stage 2: Tighten the bolt an additional 90 degrees.

Item 2: Camshaft Sprocket Bolt Installation Note

1. Install, but do not tighten the camshaft sprocket bolt.

Scheme 143

Scheme 144

1. Remove the components in the order indicated in the following illustration and table.
2. To install, reverse the removal procedure.

Scheme 145

Scheme 146

1. Remove the components in the order indicated in the following illustration and table.
2. To install, reverse the removal procedure.

Items 12-7: Camshaft, Main Bearing Caps, Oil Supply Tube, Main Bearing Cap Mounting Bolts, and Camshaft Sprocket Installation Note

1. Position the oil supply tube, the camshaft bearing caps, and the bolts. Tighten the bolts in the sequence shown in illustration in two stages. Stage 1: Tighten the bolts to 6 Nm (53 lb-in). Stage 2: Tighten the bolts to 16 Nm (12 lb-ft).
2. Install the camshaft sprocket and loosely install the bolt.
3. The camshafts must be retimed. For additional information, refer to «CAMSHAFT TIMING»(ref-194043-S15858007312005092600000) .

Scheme 147

1. Using the special tool, install the valve stem seal.

Item 5-3: Valve Spring, Valve Spring Retainers, and Valve Spring Retainer Keys Installation Note

1. Using the special tool, install the valve spring retainer keys, the valve springs and the retainers.

Item 2: Roller Follower Installation Note

Note. The roller followers must be installed in their original position.

Using the special tool, install the roller followers.

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

1. Remove the LH and RH valve covers. For additional information, refer to «VALVE COVER LH»(ref-194043-S18704149072005092600000) and «VALVE COVER RH»(ref-194043-S41257120272005092600000) .
2. Remove the cooling fan. For additional information, refer to «ENGINE COOLING»(ref-194047) .
3. Remove the components in the order indicated in the following illustration and table. To remove individual components, carry out only the listed steps.
4. To install, reverse the removal procedure.
5. Install the cooling fan. For additional information, refer to «ENGINE COOLING»(ref-194047) .
6. Install the LH and RH valve covers. For additional information, refer to «VALVE COVER RH»(ref-194043-S41257120272005092600000) and «VALVE COVER LH»(ref-194043-S18704149072005092600000) .

Scheme 155

1. Rotate the crankshaft until the camshaft for the cylinder being serviced is at base circle.
2. Using the special tool, remove the camshaft roller followers.

Scheme 156

1. Position the piston of the cylinder being serviced at top dead center (TDC).
2. Hold the valves in the cylinder head. Remove the spark plug of the cylinder being serviced. Use a suitable tool to apply air pressure to the cylinder.
3. Using the special tool, remove the valve spring retainer keys, valve spring retainers and the valve springs.

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

1. Rotate the crankshaft clockwise to position the number one cylinder at TDC.
2. Remove the retainer and position the A/C manifold tube bracket aside.
3. Install the special tool.
4. Install the special tools on the front of the LH cylinder head and tighten the top two clamp bolts to 10 Nm (89 lb-in).
5. Loosen the bolt.
6. Remove the special tools.
7. Remove the bolt and position the camshaft sprocket aside.
8. Remove the bolts in the sequence shown in illustration, and remove the camshaft bearing caps and the oil supply tube.

1. Position the oil supply tube, the camshaft bearing caps, and the bolts. Tighten the bolts in the sequence shown in illustration in two stages. Stage 1: Tighten the bolts to 6 Nm (53 lb-in). Stage 2: Tighten the bolts to 16 Nm (12 lb-ft).
2. Install the camshaft sprocket and loosely install the bolt.
3. The camshafts must be retimed. For additional information, refer to «CAMSHAFT TIMING»(ref-194043-S15858007312005092600000) .

Scheme 162

1. Using the special tool, install the valve stem seal.

Item 5, 4, and 3: Valve Spring, Valve Spring Retainer, Valve Spring Retainer Keys Installation Note

1. Using the special tool, install the valve spring, valve spring retainer, and the valve spring retainer keys.

1. Using the special tool, install the roller followers.

Scheme 163

Scheme 164

1. Remove the LH and RH valve covers. For additional information. refer to «VALVE COVER LH»(ref-194043-S18704149072005092600000) and «VALVE COVER RH»(ref-194043-S41257120272005092600000) .
2. Remove the components in the order indicated in the following illustration and table.
3. To install, reverse the removal procedure.
4. Install the LH and RH valve covers. For additional information, refer to «VALVE COVER LH»(ref-194043-S18704149072005092600000) and «VALVE COVER RH»(ref-194043-S41257120272005092600000) .

Scheme 165

1. Rotate the crankshaft until the camshaft for the cylinder being serviced is at base circle.
2. Using the special tool, remove the camshaft roller followers.

Item 2: Hydraulic Lash Adjuster Removal Note

1. Remove the hydraulic lash adjusters.

Item 1: Camshaft Roller Followers Installation Note

1. Using the special tool, install the roller followers.

Scheme 166

1. Remove the components in the order indicated in the following illustration and table.
2. To install, reverse the removal procedure.

Scheme 167

1. Remove the exhaust gas recirculation (EGR) tube. For additional information, refer to «EXHAUST GAS RECIRCULATION (EGR) VALVE»(ref-194043-S09410052932005092600000) .
2. Remove the components in the order indicated in the following illustration and table.
3. To install, reverse the removal procedure.
4. Install the EGR tube. For additional information, refer to «EXHAUST GAS RECIRCULATION (EGR) VALVE»(ref-194043-S09410052932005092600000) .

Scheme 168

MATERIALS

Scheme 169

Scheme 170

Scheme 171

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

1. Drain the engine cooling system. For additional information, refer to «ENGINE COOLING»(ref-194047) .
2. Remove the roller followers. For additional information, refer to «CAMSHAFT ROLLER FOLLOWER AND HYDRAULIC LASH ADJUSTER»(ref-194043-S40561732132005092600000) .
3. Remove the accessory drive belt tensioner. For additional information, refer to «ACCESSORY DRIVE BELT, TENSIONER AND PULLEY»(ref-194043-S33762287922005092600000) .
4. Disconnect the generator electrical connections and disconnect the pushpin.
5. Remove the generator mounting bracket assembly.
6. Remove the heater hose from the thermostat housing.
7. Disconnect the engine coolant temperature (ECT) sensor electrical connector.
8. Disconnect the upper radiator hose.
9. Position the coolant bypass hose clamp aside.
10. Remove the bolts and the thermostat housing.
11. Remove the engine wiring harness bolts and position the engine wiring harness aside.
12. Remove the engine ground strap.
13. Disconnect the radio ignition interference capacitor electrical connector.
14. Remove the bolts.
15. Remove the bolts and position the accessory bracket aside.
16. Remove the bolts and the coil bracket.
17. Remove the oil level indicator tube.
18. Disconnect all of the spark plug wires from the spark plugs.
19. Remove the engine noise shield.
20. Raise and support the vehicle. .
21. Remove the four catalytic converter-to-manifold nuts.
22. Lower vehicle.
23. Remove both of the exhaust manifolds and gaskets. Discard the gaskets and the retaining nuts.
24. Remove the RH side hydraulic chain tensioner.
25. Install the special tools.
26. Using the special tool, remove the RH camshaft bolt.
27. Remove special tools
28. Remove the RH side cassette bolt.
29. Remove the RH camshaft sprocket from the timing chain. Install a rubber band around the cassette and the timing chain.
30. Remove the LH side hydraulic chain tensioner.
31. Install the special tools. Tighten the top clamp bolts to 10 Nm (89 lb-in).
32. Remove the LH side camshaft sprocket bolt.
33. Remove special tools
34. Remove the LH side cassette bolt.
35. Remove the LH camshaft sprocket from the timing chain. Install a rubber band around the cassette and the timing chain.
36. Remove the cylinder heads. Remove the cylinder head bolts in the sequence shown in illustration. Discard all bolts. Remove and discard the head gasket.
37. Clean and inspect the mating surfaces.
38. Inspect the cylinder head and the cylinder block for flatness. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(ref-194039) .

Scheme 194

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

Scheme 201

Scheme 202

Scheme 203

Scheme 204

Scheme 205

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219

1. Position the cylinder head gasket on the block.
2. Install the cylinder head. Install new 12 mm (0.48 in) bolts and tighten in the sequence shown in illustration in two stages. Stage 1: Tighten to 12 Nm (9 lb-ft) Stage 2: Tighten to 25 Nm (18 lb-ft)
3. Install two new 8 mm (0.32 in) head bolts.
4. Tighten the eight 12 mm (0.48 in) bolts in the sequence shown in illustration in two stages. Tighten the bolts 90 degrees. Tighten the bolts an additional 90 degrees.
5. Remove the rubber band. Install the camshaft sprocket and bolt.
6. Install the RH side cassette bolt.
7. Remove the rubber band. Install the camshaft sprocket and bolt.
8. Install the LH side cassette bolt.
9. Install both of the exhaust manifolds and gaskets.
10. Connect all of the spark plug wires to the spark plugs.
11. Raise and support the vehicle.
12. Install the four catalytic converter-to-exhaust manifold nuts.
13. Lower the vehicle.
14. Install the engine noise shield.
15. Install the engine ground strap.
16. Position the engine wiring harness and install the bolts.
17. Install the thermostat housing.
18. Position the coolant bypass hose clamp.
19. Install the upper radiator hose.
20. Connect the engine coolant temperature (ECT) sensor electrical connector.
21. Install the heater hose to the thermostat housing.
22. Install the generator mounting bracket assembly.
23. Install the accessory drive belt tensioner.
24. Connect the generator electrical connections and install the pushpin.
25. Install the oil level indicator tube and bolt.
26. Install the coil bracket and the bolts.
27. Install the accessory bracket.
28. Install the bolts.
29. Connect the radio ignition interference capacitor electrical connector.
30. Install the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE BELT, TENSIONER AND PULLEY»(ref-194043-S33762287922005092600000) .
31. Turn the crankshaft clockwise to position the number one cylinder at top dead center (TDC).
32. Remove the retainer and position the A/C manifold tube bracket aside.
33. Install the special tool.
34. Install the special tools on the rear of the RH cylinder head.
35. Position the camshaft timing slots below the centerline of the camshaft to correctly fit the special tools, and install the special tools on the front of the RH cylinder head.
36. Install the special tool.
37. Tighten the bolts. Tighten the special tool top clamp bolts to 10 Nm (89 lb-in). Using the special tool, tighten the camshaft bolt.
38. Remove special tool.
39. Install the RH camshaft tensioner.
40. Remove the special tools from the RH cylinder head.
41. Install the special tools on the front of the LH cylinder head.
42. Position the camshaft timing slots below the centerline of the camshaft to correctly fit the special tools, and install the special tools on the rear of the LH cylinder head.
43. Install the special tool.
44. Tighten the bolts. Tighten the special tool top two clamp bolts to 10 Nm (89 lb-in). Tighten the camshaft bolt.
45. Remove special tool.
46. Install the LH camshaft tensioner.
47. Remove all of the special tools.
48. Install the A/C manifold tube assembly bracket.
49. Install the roller followers. For additional information, refer to «CAMSHAFT ROLLER FOLLOWER AND HYDRAULIC LASH ADJUSTER»(ref-194043-S40561732132005092600000) .
50. Fill and bleed the engine cooling system. For additional information, refer to «ENGINE COOLING»(ref-194047) .

Scheme 220

MATERIALS

Scheme 221

Scheme 222

1. With the vehicle in NEUTRAL, position it on a hoist. .
2. Disconnect the negative battery cable. For additional information, refer to «BATTERY DISCONNECT»(ref-194056-S26913125242005092600000) .
3. If removing the lower block cradle, remove the starter motor. For additional information, refer to «STARTER MOTOR»(ref-168028-S41421407872004102800000) .
4. Remove the air cleaner outlet tube. .
5. Drain the engine oil.
6. Remove the parts in the order indicated in the following illustration and table. To remove individual parts, only carry out the listed steps: LOWER BLOCK CRADLE, OIL PAN, OIL PUMP & PICK-UP TUBE REMOVAL STEPS Part Steps Oil pan 1-3 Oil pump pickup tube 1-5 Lower block cradle 7-16 Oil pump 1-18
7. To install, reverse the removal procedure.
8. Fill the engine with clean engine oil.

Scheme 223

Scheme 224

Scheme 225

Scheme 226

1. Remove the upper air deflector.
2. Remove the weatherstrip.
3. Remove and discard the screws. Remove the bolts and the fan shroud.
4. Remove the bolt.
5. Install the RH lifting eye using the previously removed bolt.
6. Install the special tools.
7. Remove the motor mount nuts.
8. Raise the engine.
9. Back the set screws off until they are below the lower block cradle boss.
10. Remove the lower block cradle.

Scheme 227

Scheme 228

Scheme 229

Scheme 230

Scheme 231

Scheme 232

Scheme 233

Scheme 234

Scheme 235

1. Remove the upper air deflector.
2. Remove the weatherstrip.
3. Remove and discard the screws. Remove the bolts and the fan shroud.
4. Remove the bolt.
5. Install the RH lifting eye using the previously removed bolt.
6. Install the special tools.
7. Remove the four bolts and the crossmember.
8. Remove the RH motor mount nut.
9. Remove the LH side through bolt and nut.
10. Raise the engine.
11. Back the set screws off until they are below the lower block cradle boss.
12. Remove the bolt from the right side of the axle housing. Discard the nut and bolt.
13. Remove the LH side lower axle housing bolt and nut. Discard the bolt and nut.
14. Remove the LH side upper axle housing axle bolt and nut. Discard the bolt and nut. Lower the axle.
15. Remove the lower block cradle.

Item 16: Lower Block Cradle Gasket Removal Note

1. Clean the sealant from the cavities on the rear main bearing cap.

Item 16: Lower Block Cradle Gasket Installation Note

1. Apply silicone in the six places shown in illustration.

Scheme 236

Scheme 237

Scheme 238

Scheme 239

Scheme 240

Scheme 241

Scheme 242

Scheme 243

Scheme 244

Scheme 245

1. Position the lower block cradle and gasket assembly.
2. Install and hand-tighten the outer bolts and nuts.
3. Install and hand-tighten the rear lower block cradle bolts.
4. Install the two rear lower block cradle-to-bell housing bolts.
5. Tighten the outer bolts.
6. Tighten the rear lower block cradle bolts.
7. Tighten the eight inserts.
8. Install the two silver covered bolts and new washer seals. Hand-tighten them at this time.
9. Install and hand-tighten the six remaining bolts.
10. Tighten the lower block cradle bolts in two stages: Stage 1: Tighten to 15 Nm (11 lb-ft). Stage 2: Tighten to 34 Nm (25 lb-ft).

Scheme 246

Scheme 247

Scheme 248

Scheme 249

1. Remove the transmission. For additional information, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION»(ref-194049) .
2. To remove individual components, carry out only the listed steps.
3. Remove the components in the order indicated in the following illustration and table.
4. To install, reverse the removal procedure.

Item 5: Crankshaft Rear Oil Seal Removal Note

1. Using the special tools, remove the crankshaft rear oil seal.

Scheme 250

1. Lubricate the crankshaft rear oil seal with clean engine oil and install the special tool. Lubricate the crankshaft rear oil seal with motor oil before installation.
2. Using the special tool, install the crankshaft rear oil seal.

Scheme 251

1. Install the flexplate. Tighten the bolts in two stages in the sequence shown in illustration. Stage 1: Tighten the bolts to 13 Nm (10 lb-in). Stage 2: Tighten the bolts to 71 Nm (52 lb-ft).

Scheme 252

Removal & Installation

Scheme 253

Scheme 254

Scheme 255

Scheme 256

Scheme 257

Scheme 258

Scheme 259

1. With the vehicle in NEUTRAL, position it on a hoist.
2. Disconnect the battery ground cable. For additional information, refer to Section «BATTERY AND CHARGING SYSTEM»(ref-194056) .
3. Remove the exhaust gas recirculation (EGR) valve tube. For additional information, refer to «EXHAUST GAS RECIRCULATION (EGR) VALVE»(ref-194043-S09410052932005092600000) .
4. Remove the upper fan shroud. Remove the bolts and, if equipped, the assembly screws. Discard the assembly screws.
5. Remove the LH radio capacitor.
6. Remove the bolt and install the lifting eye.
7. Install the special tools.
8. Remove the components in the order indicated in the following illustration and table. To remove individual components, only carry out the listed steps.
9. Illustration 1 of 3. Remove the components in the order indicated in the following illustration and table.
10. Illustration 2 of 3. Remove the components in the order indicated in the following illustration and table.
11. Illustration 3 of 3. Remove the components in the order the order indicated in the following illustration and table
12. To install, reverse the removal procedure.

Item 2: Stabilizer Bar Removal Note

1. Allow the stabilizer bar to hang freely to allow clearance for motor mount removal.

Scheme 260

1. Support the axle housing with a suitable jackstand.
2. Disconnect the vent hose from the differential housing vent tube.

Scheme 261

Scheme 262

Scheme 263

Scheme 264

Scheme 265

Scheme 266

1. With the vehicle in NEUTRAL, position it on a hoist.
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY AND CHARGING SYSTEM»(ref-194056) .
3. Remove the hood.
4. Lower the axle housing approximately 25 mm (1 in). Items 8, 9, 11 and 12: RH and LH Motor Mount and Through Bolt Removal Note Using a suitable jack, raise the engine to remove the appropriate motor mount.
5. Remove the cooling fan. For additional information, refer to «ENGINE COOLING»(ref-194047) .
6. Discharge and recover the A/C system. For additional information, refer to «CLIMATE CONTROL SYSTEM»(ref-194054) .
7. Release the fuel system pressure. For additional information, refer to «FUEL SYSTEM»(ref-194052) .
8. Remove the power steering pump pulley. For additional information, refer to «STEERING SYSTEM»(ref-194037) .
9. Remove the air cleaner outlet pipe. For additional information, refer to «REMOVAL & INSTALLATION»(ref-156578) .
10. Disconnect the fuel tube spring lock coupling. For additional information, refer to «FUEL SYSTEM»(ref-194052) .
11. Drain the cooling system. For additional information, refer to «ENGINE COOLING»(ref-194047) .
12. Remove the transmission. For additional information, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION»(ref-194049) .
13. Illustration 1 of 5. Remove the components in the order indicated in the following illustration and table.
14. Illustration 2 of 5. Remove the components in the order indicated in the following illustration and table.
15. Illustration 3 of 5. Remove the components in the order indicated in the following illustration and table.
16. Illustration 4 of 5. Remove the components in the order indicated in the following illustration and table.
17. Illustration 5 of 5. Remove the components in the order indicated in the following illustration and table.

Scheme 267

1. Disconnect the transmission control wiring harness pin-type retainers from the fuel charging wiring harness.

Item 12: Speed Control Cable Removal Note

1. Position the speed control cable aside.

Item 13: Accelerator Control Cable Removal Note

1. Position the throttle control cable aside.

Item 34: Power Steering Hose Removal Note

1. Position the power steering hose aside.

Item 36: Power Steering Hose Removal Note

1. Position the power steering hose aside.

Scheme 268

Scheme 269

Scheme 270

Scheme 271

1. Install the right side lifting eye.
2. Remove the special tools.
3. Install the left side lifting eye.
4. Install the spreader bar to the lifting eyes.
5. Attach a floor crane to the spreader bar and remove the engine.
6. Lower the engine to within 2 inches of the floor.

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

Scheme 285

Scheme 286

Scheme 287

1. Illustration 1 of 14. Remove the components in the order indicated in the following illustration and table.
2. Install the engine on a suitable engine stand and remove the engine lifting eyes.
3. Illustration 2 of 14. Remove the components in the order indicated in the following illustration and table.
4. Illustration 3 of 14. Remove the components in the order indicated in the following illustration and table.
5. Illustration 4 of 14. Remove the components in the order indicated in the following illustration and table.
6. Illustration 5 of 14. Remove the components in the order indicated in the following illustration and table.
7. Illustration 6 of 14. Remove the components in the order indicated in the following illustration and table.
8. Illustration 7 of 14. Remove the components in the order indicated in the following illustration and table.
9. Illustration 8 of 14. Remove the components in the order indicated in the following illustration and table.
10. Illustration 9 of 14. Remove the components in the order indicated in the following illustration and table.
11. Illustration 10 of 14. Remove the components in the order indicated in the following illustration and table.
12. Illustration 11 of 14. Remove the components in the order indicated in the following illustration and table.
13. Illustration 12 of 14. Remove the components in the order indicated in the following illustration and table.
14. Illustration 13 of 14. On 4x4 vehicles only, remove the components in the order indicated in the following illustration and table.
15. Illustration 14 of 14. Remove the components in the order indicated in the following illustration and table.

Scheme 288

1. Using the special tool, remove the crankshaft dampener.

Scheme 289

1. Disconnect the oil pressure switch electrical connector and remove the battery cable and harness.
2. Remove the oil pressure switch.

Scheme 290

1. Disconnect the following: Camshaft position (CMP) sensor electrical connector. Ignition coil electrical connector. Pin-type retainer.
