6-way & lumbar power seat circuit for Ford Explorer II (1994-2003)
6-way & lumbar power seat circuit
AIR BLADDER
BLK WIRE
BLK/WHT WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DN UP
ENTIRE SEAT
FRONT HEIGHT MOTOR
FRONT OF SEAT
FUSE 18
FWD/RWD MOTOR
HOT AT ALL TIMES
INFLATE VENT
LEFT FRONT POWER SEAT CONTROL SWITCH
LEFT FRONT SEAT MOTOR ASSEMBLY
LEFT LUMBAR
LEFT POWER LUMBAR MOTOR
LEFT POWER LUMBAR SEAT SWITCH
LT BLU WIRE
LT GRN WIRE
NCA WIRE
REAR HEIGHT MOTOR
REAR OF SEAT
RED WIRE
RIGHT FRONT POWER SEAT CONTROL SWITCH
RIGHT FRONT SEAT MOTOR ASSEMBLY
RIGHT LUMBAR
RIGHT POWER LUMBAR MOTOR
RIGHT POWER LUMBAR SEAT SWITCH
RWD FWD
WHT WIRE
YEL WIRE
