Wiring diagram: Computer data lines — Computer data lines, early production Ford Explorer II
All systems — 34 systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft 6
- Body computer 3
- Computer data lines 3
- Cruise control
- Defoggers
- Electronic suspension
- Engine performance 4.0l 4
- Engine performance 5.0l
- Exterior lights 8
- Ground distribution
- Headlights 3
- Horn
- Instrument cluster 4
- Interior lights 6
- Memory systems
- Navigation
- Power antenna
- Power distribution 3
- Power door locks 4
- Power mirrors 2
- Power seats 3
- Power top/sunroof
- Power windows
- Radio 5
- Shift interlocks
- Starting/charging 2
- Supplemental restraints
- Transmission 4
- Transmission 4.0l 3
- Transmission 5.0l 2
- Warning systems 3
- Wiper/washer 3
Components on these wiring diagrams 9
Click a component to highlight it on every diagram it appears on.
