TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Mounting Bracket Nut | 13-17 (17-23) |
| Front Shock Absorber Mount Nut |
| Upper | 25-34 (34-46) |
| Lower | 18-24 (24-32) |
| Rear Shock Absorber Mount Nut |
| Upper | 14-19 (19-26 ) |
| Lower | 39-53 (53-72) |
| INCH Lbs. (N.m) |
| Air Suspension Control Module Mounting Screw | 18-27 (2-3) |
| Compressor Drier Retaining Nut | 18-27 (2-3) |
| Height Sensor Bracket Bolt | 67-93 (7.5-10.5) |
| Rear Air Suspension Switch Bracket | 91-123 (10.2-13.8) |
Electronic Suspension Wiring Diagram (1998 Explorer & Mountaineer- 1 Of 2). Scheme 1
Scheme 1: Electronic Suspension Wiring Diagram (1998 Explorer & Mountaineer- 1 Of 2)
Electronic Suspension Wiring Diagram (1998 Explorer & Mountaineer - 2 Of 2). Scheme 2
Scheme 2: Electronic Suspension Wiring Diagram (1998 Explorer & Mountaineer - 2 Of 2)
Electronic Suspension Wiring Diagram (1999 Explorer & Mountaineer - 1 Of 2). Scheme 3
Scheme 3: Electronic Suspension Wiring Diagram (1999 Explorer & Mountaineer - 1 Of 2)
Electronic Suspension Wiring Diagram (1999 Explorer & Mountaineer - 2 Of 2). Scheme 4
Scheme 4: Electronic Suspension Wiring Diagram (1999 Explorer & Mountaineer - 2 Of 2)
