DIGITAL TRANSMISSION RANGE SENSOR
| CAUTION | On models equipped with 4R70W, discard outer manual control lever shaft nut. Do not reuse. The old nut will not retain torque specification. |
- Place gearshift lever in Neutral position. Remove shift cable from manual control lever. Remove manual control lever. Loosen Transmission Range (TR) sensor retaining bolts.
- Install TR Sensor Adjustor (307-351). (Scheme 11) Tighten TR sensor retaining bolts to specification. See «TORQUE SPECIFICATIONS»(ref-168318-S36109364022004110400000).
- Install manual control lever, and tighten nut to specification. See «TORQUE SPECIFICATIONS»(ref-168318-S36109364022004110400000). Check for Park gear engagement. Start engine and ensure indicated gear positions match transmission response.
Scheme 11
SYSTEM TESTS
| Symptom | Perform Test |
|---|---|
| Engine Does Not Crank Or Relay Clicks | A |
| Unusual Starter Noise | B |
| Engine Cranks Slowly | (1) |
| The Starter Spins But The Engine Does Not Crank | (2) |
| (1) Carry out the VOLTAGE DROP TEST under ON VEHICLE TESTING. (2) Inspect the starter motor mounting and engagement. Install a new starter motor. Inspect the flywheel/ring gear for damaged, missing or worn teeth. Repair as required. | |
| (1) | Carry out the VOLTAGE DROP TEST under ON VEHICLE TESTING. |
| (2) | Inspect the starter motor mounting and engagement. Install a new starter motor. Inspect the flywheel/ring gear for damaged, missing or worn teeth. Repair as required. |
SYMPTOM INDEX
STARTER RELAY
- Remove starter relay from battery junction box. Battery junction box is located on right side of engine compartment. Check relay continuity. Continuity should exist between relay terminals No. 85 and 86, and between relay terminals No. 30 and 87a. (Scheme 12)Continuity should not exist between relay terminals No. 30 and 87. If continuity is as specified, go to next step. If continuity is not as specified, replace relay.
- Using a jumper wire, apply battery voltage to relay terminal No. 85. Using a second jumper wire, ground relay terminal No. 86. Continuity should now exist between relay terminals No. 30 and 87. If continuity is not as specified, replace relay. If continuity is as specified, relay is okay at this time.
Scheme 12
STARTER MOTOR
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See appropriate COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
Expedition
For starting system wiring diagrams, see STARTING/CHARGING in SYSTEM WIRING DIAGRAMS article in ELECTRICAL.
For power distribution system wiring diagrams, see POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS article in ELECTRICAL.
For starting system wiring diagrams, see STARTING/CHARGING in SYSTEM WIRING DIAGRAMS article in ELECTRICAL.
For power distribution system wiring diagrams, see POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS article in ELECTRICAL.
For starting system wiring diagrams, see STARTING/CHARGING in SYSTEM WIRING DIAGRAMS article in ELECTRICAL.
For power distribution system wiring diagrams, see POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS article in ELECTRICAL.
For starting system wiring diagrams, see STARTING/CHARGING in SYSTEM WIRING DIAGRAMS article in ELECTRICAL.
For power distribution system wiring diagrams, see POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS article in ELECTRICAL.
