Interior Lighting System: Removal & Installation Ford Expedition II

Installation

1. To install, reverse the removal procedure.

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. Fold the mirror assembly forward.
2. Remove the Torx(R)-head screw.
3. Remove the approach lamp connector from the turn signal assembly.
4. Remove the approach lamp bulb.
5. To install, reverse the removal procedure.

Scheme 17

Scheme 18

1. Squeeze the tab and lower the approach lamp assembly.
2. Disconnect the electrical connectors.
3. To install, reverse the removal procedure.

Scheme 19

Scheme 20

1. Remove the map lamp assembly. For additional information, refer to «LAMP ASSEMBLY -MAP»(ref-209942-S32130479752005121200000) .
2. Release the clip on the bulb(s) to be replaced.
3. Remove the map lamp bulb. Remove the map lamp reflector. Remove the map lamp bulb from the clips.

1. To install, reverse the removal procedure.

Scheme 21

1. Remove the front door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-209953) .
2. Remove the interior lamp switch. Disconnect the electrical connector. Rotate the interior lamp switch counterclockwise to remove.

1. To install, reverse the removal procedure.
