Speed Control: Removal & Installation Ford Expedition II

Removal

Note. 5.4L 2-valve Triton V8 shown; others are similar.

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Remove the bolts and the accelerator control splash shield.
2. Remove the speed control actuator cable. Open the throttle valve. Slide the throttle cable back to remove it from the throttle cam nail head. Squeeze the speed control actuator cable tabs and remove from the accelerator bracket.
3. Remove the speed control actuator cable cap from the speed control actuator. Push in the locking arm on the speed control actuator cable cap. Rotate the speed control actuator cable cap counterclockwise.
4. Remove the speed control actuator cable. Press the spring retainer. Slide the core wire end out of the speed control actuator pulley and remove the speed control actuator cable.
5. Remove the cable from the retainer clips.

Scheme 24

Scheme 25

Scheme 26

1. Insert the speed control cable slug into the speed control actuator pulley slot. Gently compress the speed control actuator spring.
2. Release the compressed spring while aligning the speed control actuator cable cap tabs with the slots in the speed control actuator housing.
3. Rotate the speed control actuator cable cap until the locking arm engages.
4. Install the speed control actuator cable. Open the throttle valve. Install the speed control cable to the throttle valve. Install the speed control cable to the bracket.
5. Install the accelerator splash shield. Install the bolts.

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. Remove the speed control actuator cable cap from the speed control actuator. Push in the locking arm on the speed control actuator cable cap. Rotate the speed control actuator cable cap counterclockwise.
2. Disconnect the speed control actuator cable from the speed control actuator. Press the spring retainer. Slide the core wire end out of the speed control actuator pulley.
3. Disconnect the speed control actuator electrical connector. Press the connector tab.
4. Remove the bolts and the speed control actuator and bracket.
5. Remove the screws and the speed control actuator bracket.

Scheme 31

Scheme 32

Scheme 33

1. Install the speed control actuator bracket.
2. Install the speed control actuator.
3. Insert the speed control cable slug into the speed control actuator pulley slot. Gently compress the speed control actuator spring.
4. Release the compressed spring while aligning the speed control actuator cable cap tabs with the slots in the speed control actuator housing.
5. Rotate the speed control actuator cable cap until the locking arm engages.

Scheme 34

Scheme 35

Scheme 36

1. Remove the driver side air bag module. For additional information, refer to «AIR BAG RESTRAINT SYSTEMS»(ref-170267) .
2. Remove the speed control switch. Disconnect the electrical connector. Remove the screws.
3. Remove the horn switch. Disconnect the electrical connector. Remove the bolts.
4. Remove the speed control switch. Disconnect the wiring harness locators. Remove the screws.
5. To install, reverse the removal procedure.

Scheme 37

1. Remove the driver side air bag module. For additional information, refer to «AIR BAG RESTRAINT SYSTEMS»(ref-170267) .
2. Remove the speed control actuator switch. Release the four (A) speed control actuator switch clips and remove the (B) speed control actuator switch. Disconnect the speed control actuator switch electrical connector.
3. To install, reverse the removal procedure.

1. Remove the deactivator switch. Disconnect the electrical connector. Rotate the deactivator switch counterclockwise 45 degrees and remove it.

Scheme 38

Scheme 39

1. Release the plunger lock (if equipped). Turn the lock knob counterclockwise until the first click is felt.
2. Fully press the brake pedal.
3. Install the deactivator switch. Position the deactivator switch in the bracket and rotate it clockwise 45 degrees. Connect the electrical connector.
4. Slowly release the brake pedal and tug it moderately once the pedal reaches the rest position.
