TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Electronic hydraulic control unit (EHCU) bracket bolts to frame | 30 |
| Electronic hydraulic control unit (EHCU) bolts to bracket | 35 |
| Front anti-lock brake sensor bolt | 7-9 |
| 1/2-20 hydraulic brake tube | 23 |
| 7/16-24 hydraulic brake tube | 17 |
| Rear anti-lock brake sensor bolt | 27 |
TORQUE SPECIFICATIONS
The 4-wheel, 4-channel anti-lock brake system (4WABS) consists of the following components
- Anti-lock brake control module
- Front wheel speed sensor
- Front wheel speed sensor ring
- Hydraulic control unit
- Rear wheel speed sensor
- Rear wheel speed sensor ring
- Yellow ABS warning indicator
Scheme 1
Refer to ANTI-LOCK BRAKES for (Navigator) or ANTI-LOCK BRAKES for (Expedition) , for schematic and connector information.
