Engine Controls - Service & Adjustment Specifications: Other Ford Expedition I

Specifications 21 illustrations ~481 words

ENGINE COMPRESSION

Check engine compression with engine at normal operating temperature, all glow (diesel) or spark plugs (gasoline) removed (on dual plugs, remove exhaust side only), and throttle wide open. Ensure crankcase is full and oil is of correct viscosity. With compression gauge installed, use remote starter switch to crank engine.

Crank engine at least 5 revolutions, and record highest reading. Repeat procedure for all cylinders, using approximately same number of revolutions. Lowest compression reading should not be less than 75 percent of highest compression reading. No cylinder compression reading should be less than 100 psi (7 kg/cm 2 ).

VALVE CLEARANCE

Note. All models are equipped with hydraulic valve lifters; valve adjustment is not required. If valves are noisy or incorrect clearance is suspected, worn components are indicated. Check collapsed valve lifter clearance. See appropriate article in ENGINES.

HIGH TENSION WIRE RESISTANCE

ApplicationOhms
Except Villager7000 Per Foot
Villager9100 Per Foot

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

Note. If reusing originally installed spark plugs, reinstall them in original position. Some cylinders use platinum ground electrodes and some cylinders use platinum positive electrodes. Replacement platinum spark plugs are double platinum electrode spark plugs and are used for all cylinders.

SPARK PLUG TYPE (4-CYLINDER)

ApplicationMotorcraft No.
2.5LAWSF-32F, Or AWSTF-32F

SPARK PLUG TYPE (4-CYLINDER)

SPARK PLUG TYPE (V6)

ApplicationMotorcraft No.
3.0L OHV
Ranger(1) AWSF-32P/AWSF-32PG, Or (2) AGSF-32PP
Ranger (Flex-Fuel)AGSF-12PP
WindstarAWSF-32PP
3.3LAGSP-32FP
3.8L(1) AWSF-42EG/AWSF-42E, Or (2) AWSF-42EE
4.0L OHV & SOHC
Cylinders No. 1-3(1) AGRF-22PG Or (2) AGSF-22PP
Cylinders No. 4-6(1) AGRF-22P Or (2) AGSF-22PP
4.2L
Cylinders No. 1-3(1) AWSF-32PG, Or (2) AGSF-34EE
Cylinders No. 4-6(1) AWSF-32P, Or (2) AGSF-34EE
(1) Original spark plug. (2) Service spark plug.
(1)Original spark plug.
(2)Service spark plug.

SPARK PLUG TYPE (V6)

SPARK PLUG TYPE (V8)

ApplicationMotorcraft No.
4.6L
EconolineAWSF-32P
ExpeditionAWSF-22E, Or AWSF-32PP
F150AWSF-12E, Or AWSF-32PP
5.0L
Cylinders No. 1-4(1) AGSF-32EG, Or (2) AWSF-32EE
Cylinders No. 5-8(1) AGSF-32E, Or (2) AWSF-32EE
5.4L (2V)
Econoline (Except CNG), Expedition & F250/F350 PickupAWSF-22E
Econoline & F150 Pickup (CNG)(3) AWSF-22FM1, Or (4) AGSF-22FMI
F150 Pickup (Lightning)AGSF-12E, Or AGSF-12FMI
F150 Pickup (Except Lightning)AWSF-12E, Or AWSF-22E
Navigator (4V)AWSF-22E, Or AWSF-32P
(1) Original spark plug. (2) Service spark plug. (3) Applies to vehicles with build dates before February, 1999. (4) Applies to vehicles with build dates from February, 1999 and up.
(1)Original spark plug.
(2)Service spark plug.
(3)Applies to vehicles with build dates before February, 1999.
(4)Applies to vehicles with build dates from February, 1999 and up.

SPARK PLUG TYPE (V8)

SPARK PLUG TYPE (V10)

ApplicationMotorcraft No.
6.8L
EconolineAWSF-22E, Or AWSF-22W
Excursion & PickupAWSF-22E

SPARK PLUG TYPE (V10)

FIRING ORDER & TIMING MARKS

Note. Use illustrations for firing order and timing marks. (Scheme 1)- (Scheme 21). Timing mark information is not available for all models.

Identifying Firing Order & Timing Marks (2.5L). Scheme 1

Scheme 1: Identifying Firing Order & Timing Marks (2.5L)

Scheme 2

Scheme 2: Spark Plug Wire Routing (2.5L)

Scheme 3

Scheme 3: Firing Order & Timing Marks (3.0L - Windstar)

Scheme 4

Scheme 4: Spark Plug Wire Routing (3.0L - Windstar)

Identifying Firing Order & Timing Marks (3.0L - VIN "U &V" & 4.0L - VIN "X"). Scheme 5

Scheme 5: Identifying Firing Order & Timing Marks (3.0L - VIN "U &V" & 4.0L - VIN "X")

Scheme 6

Scheme 6: Spark Plug Wire Routing (4.0L VIN "X")

Identifying Firing Order (3.3L). Scheme 7

Scheme 7: Identifying Firing Order (3.3L)

Scheme 8

Scheme 8: Firing Order & Timing Marks (3.8L)

Scheme 9

Scheme 9: Spark Plug Wire Routing (3.8L)

Identifying Firing Order & Timing Marks (4.0L - VIN "E"). Scheme 10

Scheme 10: Identifying Firing Order & Timing Marks (4.0L - VIN "E")

Scheme 11

Scheme 11: Spark Plug Wire Routing (4.0L - VIN "E")

Identifying Firing Order & Timing Marks (4.2L). Scheme 12

Scheme 12: Identifying Firing Order & Timing Marks (4.2L)

Scheme 13

Scheme 13: Spark Plug Wire Routing (4.2L)

Identifying Firing Order & Timing Marks (4.6L With Light-Duty Emissions). Scheme 14

Scheme 14: Identifying Firing Order & Timing Marks (4.6L With Light-Duty Emissions)

Scheme 15

Scheme 15: Spark Plug Wire Routing (4.6L With Light-Duty Emissions)

Identifying Firing Order & Timing Marks (5.0L). Scheme 16

Scheme 16: Identifying Firing Order & Timing Marks (5.0L)

Scheme 17

Scheme 17: Spark Plug Wire Routing (5.0L)

Identifying Firing Order & Timing Marks (5.4L). Scheme 18

Scheme 18: Identifying Firing Order & Timing Marks (5.4L)

Scheme 19

Scheme 19: Ignition Coils (5.4L & 6.8L)

Identifying Firing Order (6.8L). Scheme 20

Scheme 20: Identifying Firing Order (6.8L)

Identifying Firing Order (7.3L Diesel). Scheme 21

Scheme 21: Identifying Firing Order (7.3L Diesel)

IGNITION TIMING

Note. On all models with distributorless electronic ignition, manufacturer does not recommend checking ignition timing, as faulty readings are common and timing is not adjustable.

ApplicationDegrees BTDC
Villager13-17
All Others8-10

BASE IGNITION TIMING

FUEL PUMP

Note. For fuel pressure specifications, see FUEL PRESSURE SPECIFICATIONS article.

IDLE SPEED & MIXTURE

Note. Idle mixture is not adjustable. For additional information, see SELF-DIAGNOSTICS - EEC-V article.

THROTTLE POSITION (TP) SENSOR

Note. Throttle Position (TP) sensor is not serviceable. If TP sensor service is required, see CIRCUIT TEST DH in SELF-DIAGNOSTICS - EEC-V article.

TP SENSOR OUTPUT (VILLAGER)

Throttle Position(1) Voltage
Closed.4
1/41.3
Half Open2.2
3/43.1
Fully Open4.1
(1) Values may vary by 15 percent.
(1)Values may vary by 15 percent.

TP SENSOR OUTPUT (VILLAGER)

TP SENSOR OUTPUT (EXCEPT VILLAGER)

Throttle Angle Degrees(1) Volts
Clockwise
201.00
402.00
603.00
803.80
1004.50
Counterclockwise
01.00
202.00
403.00
603.80
804.65
(1) Throttle position may vary by 6 percent. For testing, refer to TEST DH in SELF - DIAGNOSTICS - EEC-V article.
(1)Throttle position may vary by 6 percent. For testing, refer to TEST DH in SELF - DIAGNOSTICS - EEC-V article.

TP SENSOR OUTPUT (EXCEPT VILLAGER)
