TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Air Spring Lower Bolt | 56-76 (76-103) |
| Air Spring Upper Nut | 37-44 (50-60) |
| Air Suspension Switch Bracket Bolt | 8-10 (10.2-13.8) |
| Height Sensor Ball Stud Nut | 8-10 (10.2-13.8) |
| Shock Absorber Lower Mount Nut | 56-76 (76-103) |
| Shock Absorber Upper Mount Nut | 37-44 (50-60) |
| INCH Lbs. (N.m) | |
| Compressor Drier Mounting Screw | 67-92 (7.6-10.4) |
| Compressor Mounting Bracket Nut | 67-92 (7.6-10.4) |
TORQUE SPECIFICATIONS
