Instrument cluster — Instrument cluster circuit Ford Escort V facelift 2

Components on these wiring diagrams 36

Click a component to highlight it on every diagram it appears on.

• Airbag Ind
• Anti- Slosh/ Bulb Proveout Module
• Anti- Theft Ind
• Anti-Lock Brake Control Module
• Anti-Lock Ind
• Battery Junction Box
• Brake Fluid Level Switch
• Central Junction Box
• Charge Ind
• Check Engine Coolant Ind
• Check Engine Ind
• Daytime Running Lamps Module
• Engine Coolant Level Switch
• Engine Coolant Temp. Gauge
• Engine Oil Pressure Ind
• Engine Oil Pressure Switch
• Fuel Pump Module
• Hi-Beam Ind
• Illumination
• Instrument — Cluster
• Instrumentation Engine Coolant Temperature Sender
• Joint Connector 1
• Joint Connector 6
• Joint Connector 7
• Liftgate Ajar Ind
• Liftgate Latch Switch
• M/T Only
• Park Brake Switch
• Powertrain Control Module
• Remote Anti-Theft Personality Module
• Speedometer
• Tachometer
• Upshift Ind
• Vehicle Speed Sensor
• W/O Drl
• Warning Chime Module
