Fuse & Circuit Breaker Identification
- 1 - 15 Amp STOP Brake Lamps, Shift Lock
- 2 - 15 Amp TAIL Instrument Cluster Illumination, License Plate Lamp, Parking Lamps, Side Marker Lamps, Tail Lamps, (Radio, Climate Control Illumination)
- 3 - Not Used SUN ROOF
- 4 - 10 Amp ASC Speed Control
- 5 - Not Used
- 6 - 30 Amp DOOR LOCK Power Door Locks
- 7 - 15 Amp HORN Horn
- 8 - 15 Amp AIR CONDITIONING A/C, Clutch
- 9 - 10 Amp METER Backup Lamps, Shift Lock, Gauges, Speed Control, Turn Signals, Key-In-Ignition Reminder Chime
- 10 - 20 Amp WIPER Windshield Wipers and Washer
- 11 - 10 Amp REAR WIPER Rear Wiper and Washer
- 12 - 15 Amp HAZARD Hazard Flashers, Turn Signals
- 13 - 10 Amp ROOM Clock, Interior Lamp, Luggage Compartment Lamp, Safety Belt Warning Chime, Radio Power
- 14 - 15 Amp ENGINE Engine Control System
- 15 - 5 Amp MIRRORS Power Mirrors
- 16 - Not Used
- 17 - Not Used
- 18 - 10 Amp FOG Daytime Running Lamps, Fog Lamps
- 19 - Not Used
- 20 - 20 Amp CIGAR Cigar Lighter
- 21 - 15 Amp RADIO Radio (Premium Sound)
Scheme 1
Scheme 1: ENGINE COMPARTMENT FUSE PANEL IDENTIFICATION
Scheme 2
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- 1 - 30 Amp FUEL INJECTION Fuel Injection System, Air Bags
- 2 - 30 Amp DEFOG Rear Window Defroster
- 3 - 100 Amp MAIN Overall Circuit Protection
- 4 - 40 Amp BTN Passenger Compartment Fuses 1, 2, 6, 12, 13, 7
- 5 - 60 Amp ABS Anti-Lock Brake System (ABS)
- 6 - 40 Amp COOLING FAN Cooling Fan
- 7 - HEAD Head Lamp Relay
- 8 - Not Used
- 9 - 10 Amp OBD II On-Board Diagnostics
- 10 - 20 Amp FUEL PUMP Fuel Pump
- 11 - 20 Amp HEAD RH Passenger Side Headlamps
- 12 - 20 Amp HEAD LH Driver Side Headlamps
