Wiring diagram: Computer data lines 1.8l — 1.8l, computer data lines Ford Escort V facelift
All systems
- Anti-lock brakes
- Computer data lines 1.8l
- Computer data lines 1.9l
- Cruise control
- Defoggers
- Engine performance 1.8l 2
- Engine performance 1.9l
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster 2
- Interior lights
- Passive restraints
- Power distribution
- Power door locks
- Power mirrors
- Power top/sunroof
- Power windows 2
- Radio 2
- Shift interlocks
- Starting/charging 1.8l 3
- Starting/charging 1.9l 3
- Supplemental restraints
- Transmission 1.8l
- Transmission 1.9l
- Wiper/washer 2
1.8l, computer data lines — Computer data lines 1.8l Ford Escort V facelift
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
