Fuse & Circuit Breaker Identification
- 10 Amp - Daytime Running Lamps
- 15 Amp - Hazard Flasher
- 10 Amp - Engine Controls, RAP System, Radio, Shift Lock, Courtesy Lamps, Starting System, Warning Chime, Instrument Cluster
- 15 Amp - Electronic Automatic Transaxle, Ignition System, Constant Cotnrol Relay Module (PCM Relay)
- 5 Amp - Power Mirrors, Radio, RAP System
- LOCK 30 Amp - Power Door Locks
- 15 Amp - Horn, Shift Lock
- CONDITIONING 15 Amp - A/C-Heater, ABS
- 10 Amp - Backup Lamps, Engine Coolant Level Switch, Instrument Cluster, Rear Window Defrost, Shift Lock, Warning Chime, Turn Signal Switch
- 20 Amp - Windshield Wipers and Washer, Blower Motor Relay
- 20 Amp - Stop Lamps, Brake Pressure Switch
- 15 Amp - Exterior Lamps, Instrument Illumination
- ROOF 15 Amp - Power Moonroof
- 10 Amp - Speed Control
- WINDOW 30 Amp (Circuit Breaker) Power Windows
- 20 Amp - Cigar Lighter
- BAG 10 Amp - Air Bags
- 10 Amp - Daytime Running Lamps, Fog Lamps
- 15 Amp - Premium Sound Amplifier, CD Changer
- INJ. 10 Amp - HO2S, Evaporative Emission Purge Flow Sensor
- 30 Amp (Circuit Breaker) Blower Motor Relay
Scheme 1
Scheme 1: INSTRUMENT PANEL FUSE PANEL IDENTIFICATION - SEDAN/WAGON
- WIPER 10 Amp - Daytime Running Lamps, Liftgate Wiper/Washer
- 15 Amp - Hazard Flasher
- 10 Amp - Engine Controls, RAP System, Radio, Shift Lock, Courtesy Lamps, Starting System, Warning Chime
- 15 Amp - Air Bag, Engine Controls, TR Sensor
- 5 Amp - Power Mirrors, Radio, Remote Keyless Entry
- LOCK 30 Amp - Power Door Locks
- 15 Amp - Horn, Shift Lock
- COND 15 Amp - A/C-Heater, ABS
- 10 Amp - Backup Lamps, Engine Controls, Instrument Cluster, Rear Window Defrost, Shift Lock, Warning Chime, Turn Signal Switch
- 20 Amp - Windshield Wipers and Washer, Blower Motor Relay
- 20 Amp - Stop Lamps
- 15 Amp - Exterior Lamps, Instrument Illumination
- 10 Amp - Speed Control
- 20 Amp - Cigar Lighter
- BAG 10 Amp - Joint Connector, Air Bag Diagnostic Monitor
- 10 Amp - Daytime Running Lamps, Fog Lamps
- 15 Amp - Premium Sound Amplifier, CD Changer
- INJECTOR 10 Amp - HO2S, Evaporative Emission Purge Flow Sensor
- WINDOW 30 Amp (Circuit Breaker) Power Windows
- 30 Amp (Circuit Breaker) A/C Heater
Scheme 2
Scheme 2: ENGINE COMPARTMENT FUSE PANEL IDENTIFICATION - COUPE
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- INJECTION 30 Amp - Air Bags, Constant Control Relay Module (PCM Relay), Generator
- 30 Amp - Rear Window Defroster
- 100 Amp - Overall Circuit Protection
- 40 Amp - Hazard, Stop, Door Lock, Tail, Room, and Horn Fuses of the I/P Fuse Panel
- 60 Amp - ABS Main Relay
- FAN 40 Amp - Constant Control Relay Module (Cooling Fan)
- II 10 Amp - Data Link Connector, Instrument Cluster
- PUMP 20 Amp - Constant Control Relay Module (Fuel Pump)
- RH 10 Amp - Headlamps
- LH 10 Amp - Headlamps
Scheme 3
Scheme 3: ENGINE COMPARTMENT FUSE PANEL IDENTIFICATION - SEDAN/WAGON
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- INJECTION 30 Amp - Air Bags, Engine Controls, Generator
- 30 Amp - Rear Window Defroster
- 100 Amp - Charging System, BTN, Cooling Fan, Fuel Pump, OBD-II, ABS Fuses, Ignition Switch, Headlamps
- 40 Amp - Hazard
- 60 Amp - ABS Main Relay
- FAN 40 Amp - Constant Control Relay Module
- II 10 Amp - Data Link Connector, Instrument Cluster
- PUMP 20 Amp - Engine Controls
- RH 10 Amp - Headlamps
- LH 10 Amp - Headlamps
