Power windows — Power windows circuit, w/ door module Ford Escape IV
All systems — 39 systems
- Active bodyworks 2
- Air conditioning 2
- Anti-lock brakes 2
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan 2
- Cruise control
- Defoggers 2
- Electronic power steering
- Engine performance 1.5l turbo
- Engine performance 2.0l turbo
- Engine performance 2.5l hybrid
- Engine performance 2.5l plug-in hybrid
- Exterior lights 3
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 2
- Navigation 6
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 4
- Power top/sunroof
- Power windows 2
- Radio 2
- Shift interlock 2
- Starting/charging 2
- Supplemental restraints
- Transmission 1.5l turbo 2
- Transmission 2.0l turbo 2
- Transmission 2.5l hybrid 2
- Transmission 2.5l plug-in hybrid 2
- Trunk, tailgate, fuel door 2
- Warning systems 2
- Wiper/washer
Components on these wiring diagrams 26
Click a component to highlight it on every diagram it appears on.
