Transfer Case - Power Transfer Unit (Ptu): Removal & Installation Ford Escape III

Transfer Case 11 illustrations ~326 words

Removal

  1. Remove the PTU output flange. Refer to «OUTPUT FLANGE»(ref-569566-S05941400102013072700000) .

Installation

  1. Special Tool(s): Installer, Output Seal 308-877.
  2. Install the PTU output flange. Refer to «OUTPUT FLANGE»(ref-569566-S05941400102013072700000) .

All vehicles

Scheme 1

Scheme 1: Removal
  1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) . Vehicles equipped with 2.0L GTDI
  2. Remove the catalytic converter. Refer to «EXHAUST SYSTEM»(ref-569570) . All vehicles

All vehicles

  1. Tighten to 11 Nm (97 lb-in). Vehicles equipped with 2.0L GTDI .
  2. Install the catalytic converter. Refer to «EXHAUST SYSTEM»(ref-569570) .
ItemSpecification
Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant XY-75W140-QL (US); CXY-75W140-1L (Canada)WSL-M2C192-A and GL-5

MATERIAL SPECIFICATIONS

All vehicles

Scheme 2

Scheme 2: Removal

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6
  1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
  2. Remove the driveshaft. Refer to «DRIVESHAFT»(ref-569565) . Vehicles equipped with 1.6L GTDI
  3. Vehicles equipped with 2.0L GTDI
  4. Remove the Heated Oxygen Sensor. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-569601) .
  5. Remove the catalytic converter. Refer to «EXHAUST SYSTEM»(ref-569570) . All vehicles
  6. Remove the RH halfshaft. Refer to «FRONT DRIVE HALFSHAFTS»(ref-569562) .

All vehicles

Scheme 7

Scheme 7: Installation

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11
  1. Inspect and replace the o-ring seal if damaged.
  2. Tighten to 63 Nm (46 lb-ft).
  3. Tighten to 63 Nm (46 lb-ft).
  4. Tighten to 25 Nm (18 lb-ft). Tighten to 63 Nm (46 lb-ft).
  5. Install the RH halfshaft. Refer to «FRONT DRIVE HALFSHAFTS»(ref-569562) .
  6. Tighten to 11 Nm (97 lb-in). Vehicles equipped with 2.0L GTDI
  7. Install the catalytic converter. Refer to «EXHAUST SYSTEM»(ref-569570) .
  8. Tighten to 5 Nm (44 lb-in). Tighten to 11 Nm (97 lb-in). Vehicles equipped with 1.6L GTDI
  9. All vehicles
  10. Install the driveshaft. Refer to «DRIVESHAFT»(ref-569565) .
  11. Apply the specified lubricant to the specified component.
  12. Tighten to 34 Nm (25 lb-ft).
  1. Remove the PTU. Refer to «POWER TRANSFER UNIT (PTU)»(ref-569566-S38521648302013072700000) .
  1. Special Tool(s): Handle 205-153 (T80T-4000-W), Installer, Inboard Cover Seal 308-875.
  2. Tighten to 14 Nm (124 lb-in).
  3. Install the PTU. Refer to «POWER TRANSFER UNIT (PTU)»(ref-569566-S38521648302013072700000) .
