Seat Latch Actuator Adjustment
| WARNING | Before beginning any service procedure in this information, refer to SAFETY WARNINGS in SERVICE INFORMATION . Failure to follow this instruction may result in serious personal injury. |
Note. 60 percent seat shown in illustration, 40 percent seat similar.
Scheme 127
Scheme 128
Scheme 129
Scheme 130
- NOTE: Hold the seat cushion in an upright position while locking the compensator tab. Do not stretch the cable while locking the tab as this may result in the seat latch not operating correctly.
- NOTE: The seat cushion trim strap must be placed behind and below the safety restraint buckle prior to lowering the seat cushion and attaching the seat cushion front fasteners. NOTE: The center safety restraint buckle must be held in the upright position while lowering the seat cushion. If center safety belt buckle is not positioned correctly this will result in the seat cushion not being installed correctly. 40 Nm (30 lb-ft).
