Fuel Tank Draining

SPECIAL TOOLS Fuel Storage Tanker 164-R3202 or equivalent

Scheme 5

Scheme 5: Fuel Tank Draining

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8
  1. WARNING: Before beginning any service procedure in this information, refer to SAFETY WARNINGS in «SERVICE INFORMATION»(ref-569549) . Failure to follow this instruction may result in serious personal injury.
  2. Disconnect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
  3. NOTE: The supplement refueling adapter is located in the luggage compartment. Install the supplemental refueling adapter and a length of semi-rigid fuel drain tube into the Easy Fuel ™ (capless) fuel tank filler pipe.
  4. NOTE: Some residual fuel may remain in the fuel tank filler pipe. Carefully drain into a suitable container.

Disconnect - Type I

WARNINGBefore beginning any service procedure in this information, refer to SAFETY WARNINGS in SERVICE INFORMATION . Failure to follow this instruction may result in serious personal injury.

Note. When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube or damage to the tube or connector retaining clip can occur. Apply clean engine oil to the end of the tube before inserting the tube into the connector.

Note. Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is essential that absolute cleanliness is observed when working with these components or component damage can occur. Always install plugs to any open orifices or tubes.

Note. Do not use any tools. The use of tools may cause a deformity in the clip components which may cause fuel leaks.

  1. If servicing a liquid fuel tube quick connect coupling, release the fuel system pressure. Refer to «FUEL SYSTEM PRESSURE RELEASE»(ref-569597-S13557612942013072700000) .
  2. Disconnect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
  3. NOTE: When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube. Separate the tabs of the retainer clip and pull it to the outward position in the quick connect coupling.
  4. Depress the retainer clip and disconnect the quick connect coupling from the tube.

Connect - Type I

  1. Inspect and clean both quick coupling ends.
  2. Install the quick connect coupling onto the tube.
  3. Press the retainer clip into the quick connect coupling body until flush and the tabs are locked in place.
  4. Pull on the quick connect coupling to make sure it is securely fastened.
  5. Connect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .

Disconnect - Type III

WARNINGBefore beginning any service procedure in this information, refer to SAFETY WARNINGS in SERVICE INFORMATION . Failure to follow this instruction may result in serious personal injury.

Note. When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube or damage to the tube or connector retaining clip can occur. Apply clean engine oil to the end of the tube before inserting the tube into the connector.

Note. Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is essential that absolute cleanliness is observed when working with these components or component damage can occur. Always install plugs to any open orifices or tubes.

Note. Do not use any tools. The use of tools may cause a deformity in the clip components which may cause fuel leaks.

  1. If servicing a liquid fuel tube quick connect coupling, release the fuel system pressure. Refer to «FUEL SYSTEM PRESSURE RELEASE»(ref-569597-S13557612942013072700000) .
  2. Disconnect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
  3. NOTE: When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube. Release the lock tab on the quick connect coupling.

Connect - Type III

  1. Inspect and clean both quick connect coupling ends.
  2. Release the lock tab and install the quick connect coupling onto the fitting.
  3. Apply the lock tab into the latched position.
  4. Pull on the quick connect coupling to make sure it is securely fastened.
  5. Connect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .

Disconnect - Type V

WARNINGBefore beginning any service procedure in this information, refer to SAFETY WARNINGS in SERVICE INFORMATION . Failure to follow this instruction may result in serious personal injury.

Note. When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube or damage to the tube or connector retaining clip can occur. Apply clean engine oil to the end of the tube before inserting the tube into the connector.

Note. Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is essential that absolute cleanliness is observed when working with these components or component damage can occur. Always install plugs to any open orifices or tubes.

Note. Do not use any tools. The use of tools may cause a deformity in the clip components which may cause fuel leaks.

Scheme 9

Scheme 9

Scheme 10

Scheme 10
  1. If servicing a liquid fuel tube quick connect coupling, release the fuel system pressure. Refer to «FUEL SYSTEM PRESSURE RELEASE»(ref-569597-S13557612942013072700000) .
  2. Disconnect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
  3. NOTE: When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube. Press the tabs of the retainer clip and pull it to the outward position.
  4. Separate the quick connect coupling from the tube.

Scheme 11

Scheme 11: Connect - Type V
  1. Inspect and clean both quick connect coupling ends.
  2. Install the quick connect coupling onto the tube until it is fully seated.
  3. Pull on the quick connect coupling to make sure it is securely fastened.
  4. Connect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .

Disconnect - Type VI

WARNINGBefore beginning any service procedure in this information, refer to SAFETY WARNINGS in SERVICE INFORMATION . Failure to follow this instruction may result in serious personal injury.

Note. When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube or damage to the tube or connector retaining clip can occur. Apply clean engine oil to the end of the tube before inserting the tube into the connector.

Note. Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is essential that absolute cleanliness is observed when working with these components or component damage can occur. Always install plugs to any open orifices or tubes.

Note. Do not use any tools. The use of tools may cause a deformity in the clip components which may cause fuel leaks.

Scheme 12

Scheme 12
  1. If servicing a liquid fuel tube quick connect coupling, release the fuel system pressure. Refer to «FUEL SYSTEM PRESSURE RELEASE»(ref-569597-S13557612942013072700000) .
  2. Disconnect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
  3. NOTE: When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube. Press the tabs of the retainer clip and pull it to the outward position.
  4. Separate the quick connect coupling from the tube.

Scheme 13

Scheme 13: Connect - Type VI
  1. Install the quick connect coupling onto the tube until it is fully seated.
  2. Pull on the quick connect coupling to make sure it is securely fastened.
  3. Connect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .

Disconnect - Type VII

WARNINGBefore beginning any service procedure in this information, refer to SAFETY WARNINGS in SERVICE INFORMATION . Failure to follow this instruction may result in serious personal injury.

Note. When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube or damage to the tube or connector retaining clip can occur. Apply clean engine oil to the end of the tube before inserting the tube into the connector.

Note. Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is essential that absolute cleanliness is observed when working with these components or component damage can occur. Always install plugs to any open orifices or tubes.

Note. Do not use any tools. The use of tools may cause a deformity in the clip components which may cause fuel leaks.

Scheme 14

Scheme 14
  1. If servicing a liquid fuel tube quick connect coupling, release the fuel system pressure. For additional information, refer to «FUEL SYSTEM PRESSURE RELEASE»(ref-569597-S13557612942013072700000) .
  2. Disconnect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
  3. NOTE: When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube. Push the tube toward the connection and pull it to the outward position.
  4. Separate the quick connect coupling from the tube.

Scheme 15

Scheme 15: Connect - Type VII
  1. Install the quick connect coupling onto the tube until it is fully seated.
  2. Pull on the quick connect coupling to make sure it is securely fastened.
  3. Connect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
