Driveshaft: Specifications Ford Escape III

Driveshaft & Universal Joints 6 illustrations ~141 words

Torque Specifications

DescriptionNm
Center bearing support bolts25
Center bearing support bracket bolts25
Front driveshaft-to-Power Transfer Unit (PTU) flange bolts35
Rear driveshaft-to-pinion flange bolts35

TORQUE SPECIFICATIONS

Refer to DRIVELINE SYSTEM - GENERAL INFORMATION .

Scheme 18

Scheme 18: Removal

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23
  1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(/ford/escape/iii-2012-2015/remont/oem-general-information/#jacking-lifting) .
  2. Discard the specified component. Follow local disposal regulations. To install, tighten the new bolts to 35 Nm (26 lb-ft).
  3. NOTE: Do not remove driveshaft from the PTU flange by pulling on the driveshaft tube. Damage to the CV-joint can result. Marker. Center punch.
  4. Discard the specified component. Follow local disposal regulations. To install, tighten the new bolts to 35 Nm (26 lb-ft).
  5. NOTE: Do not remove driveshaft from the pinion flange by pulling on the driveshaft tube. Damage to the CV-joint can result. Marker. Screwdriver.
  6. To install, tighten to 25 Nm (18 lb-ft).
