Engine Mechanical - 2.5L - (Except Hybrid): Maintenance Ford Escape II

Mechanical 7 illustrations ~377 words

Lubrication System

The engine lubrication system operates as follows

  1. Oil is drawn into the oil pump through the oil pump screen cover and tube in the sump of the oil pan.
  2. Oil is pumped through the oil filter on the left front side of the cylinder block.
  3. Oil enters the main gallery where it is distributed to the crankshaft main journals and to the cylinder head.
  4. From the main journals, the oil is routed through cross-drilled passages in the crankshaft to lubricate the connecting rod bearings. Controlled leakage through the crankshaft main bearings and connecting rod bearings is slung radially outward to cool and lubricate the cylinder walls as well as the entire connecting rod, piston and piston ring assembly.

Refer to ENGINE SYSTEM-GENERAL INFORMATION for basic mechanical concerns or refer to the INTRODUCTION - GASOLINE MODELS for driveability concerns.

Scheme 144

Scheme 144: Valve Clearance Check
  1. Remove the valve cover. For additional information, refer to «VALVE COVER»(ref-344116-S38674428972009101600000) .
  2. Remove the 5 bolts, the pin-type retainer (not shown) and the RH splash shield. To install, tighten to 9 Nm (80 lb-in).
  3. Use a feeler gauge to measure the clearance of each valve and record its location.
  4. The acceptable clearances after being fully installed are: intake: 0.22-0.28 mm (0.008-0.011 in). exhaust: 0.27-0.33 mm (0.010-0.013 in). Select tappets using this formula: tappet thickness = measured clearance + the existing tappet thickness - nominal clearance. Select the closest tappet size to the ideal tappet thickness available and mark the installation location.
  5. If any tappets do not measure within specifications, install new tappets in these locations. For additional information, refer to «VALVE TRAIN COMPONENTS - EXPLODED VIEW»(ref-344116-S03223658852009101600000) and «VALVE TAPPETS»(ref-344116-S29513620062009101600000) .

Engine Lubrication Components - Exploded View

Oil Filter Adapter, Oil Filter Element and Engine Oil Pressure (EOP) Switch

Scheme 145

Scheme 145: Engine Lubrication Components - Exploded View
ItemPart NumberDescription
114A464Engine Oil Pressure (EOP) switch electrical connector (part of 12B637)
29278EOP switch
36C684Oil filter drain plug
4W707718Oil filter drain plug O-ring seal
56A832Oil filter cover
66885Oil filter cover O-ring seal
76744Oil filter element
8W500225Oil filter adapter bolt (4 required)
96884Oil filter adapter
106A636Oil filter adapter gasket

ITEM DESCRIPTION

Oil Filter Adapter, Spin on Oil Filter and Engine Oil Pressure (EOP) Switch

Scheme 146

Scheme 146
ItemPart NumberDescription
114A464Engine Oil Pressure (EOP) switch electrical connector (part of 12C508)
29278EOP switch
36731Spin on oil filter
4W500225Oil filter adapter bolt (4 required)
56884Oil filter adapter
66A636Oil filter adapter gasket

ITEM DESCRIPTION

Oil Pan, Oil Pump Screen and Pickup Tube, Front Wheel Drive (FWD) Vehicles

Note. Automatic transmission shown, manual transmission similar.

Scheme 147

Scheme 147
ItemPart NumberDescription
1W500121Upper bellhousing-to-engine bolts
2W500121LH bellhousing-to-engine bolt
3W500125LH bellhousing-to-engine bolt

ITEM DESCRIPTION

Oil Pan, Oil Pump Screen and Pickup Tube, All-Wheel Drive (AWD) Vehicles

Scheme 148

Scheme 148
ItemPart NumberDescription
1W500125RH engine-to-bellhousing bolts (2 required for automatic transaxle) (1 required for manual transaxle)
2W707386RH engine bracket-to-Power Transfer Unit (PTU) bolts

ITEM DESCRIPTION

Oil Pan, Oil Pump Screen and Pickup Tube

Scheme 149

Scheme 149
ItemPart NumberDescription
1W500120RH engine-to-bellhousing bolts (Front Wheel Drive (FWD) vehicles)
2W500121Bellhousing-to-oil pan bolt (2 required)
3W500121Oil pan-to-bellhousing bolt (2 required)
46730Oil pan drain plug
5W500215Engine front cover-to-oil pan bolt (4 required)
6W706284Oil pan bolt (2 required)
7W500224Oil pan bolt (11 required)
86675Oil pan
9W706282Oil pump screen and pickup tube bolt (2 required)
106622Oil pump screen and pickup tube
116625Oil pump screen and pickup tube gasket

ITEM DESCRIPTION

Oil Pump

Scheme 150

Scheme 150
ItemPart NumberDescription
1W703651Oil pump drive chain tensioner shoulder bolt (2 required)
26C271Oil pump drive chain tensioner
36A895Oil pump drive chain
4W704397Oil pump sprocket bolt
56652Oil pump sprocket
6W703647Oil pump bolt (4 required)
76600Oil pump

ITEM DESCRIPTION
