Drum Brake System: Component Locations Ford Escape II

Mechanical - Hydraulic 6 illustrations ~216 words

Special Tool(s)

SPECIAL TOOL REFERENCE CHART Brake Adjustment Gauge 206-D002 (D81L-1103-A) or equivalent

Scheme 8

Scheme 8: Special Tool(s)
Scheme 8: Special Tool(s)

Scheme 9

Scheme 9
Scheme 9
  1. Remove the brake drum. For additional information, refer to «BRAKE DRUM»(ref-344074-S10809840682009101600000) .
  2. Using the Brake Adjustment Gauge, measure the inside diameter of the brake drum.
  3. Position the Brake Adjustment Gauge on the brake shoes and linings and adjust accordingly.
  4. Install the brake drum. For additional information, refer to «BRAKE DRUM»(ref-344074-S10809840682009101600000) .

Scheme 10

Scheme 10: Drum Brake System - Exploded View
Scheme 10: Drum Brake System - Exploded View
ItemPart NumberDescription
1Brake tube fitting (part of 2265 RH/2268 LH)
22276Wheel cylinder bolts
32261Wheel cylinder
42B223Brake flexible hose clip
5W500220Brake flexible hose bracket bolt
6Brake flexible hose fitting (part of 2A361)
7Plug (part of kit 2128)
8Brake shoe retaining pins (part of kit 2A225)
9Upper return spring (part of kit 2A225)
102200Brake shoe (kit)
112040 RH/2041 LHSelf-adjuster assembly
121126Brake drum
13Brake shoe retaining springs (part of kit 2A225)
14Brake shoe retaining spring plates (part of kit 2A225)
15Lower return spring (part of kit 2A225)
162A442Brake flexible hose
172216Backing plate bolts
182211 RH/2212 LHBacking plate

ITEM DESCRIPTION CHART

SPECIAL TOOL REFERENCE CHART Brake Drum Gauge 134-R0191 or equivalent

Scheme 11

Scheme 11: Special Tool(s)
Scheme 11: Special Tool(s)

Scheme 12

Scheme 12: Removal
Scheme 12: Removal
  1. Remove the wheel and tire. For additional information, refer to «WHEELS & TIRES»(ref-344055) .
  2. If the brake drum binds on the brake shoes, retract the brake shoes. Move the brake shoe adjuster actuator lever away from the adjuster. Rotate the brake shoe adjuster screw upward to retract the brake shoes.
  3. Remove the brake drum.

Scheme 13

Scheme 13: Installation
Scheme 13: Installation
  1. Using the Brake Drum Gauge, measure the inside diameter of the brake drum. Install a new brake drum if the inside diameter exceeds the specification stamped on the outside face of the brake drum.
  2. Adjust the rear brakes. For additional information, refer to «BRAKE SHOE ADJUSTMENT»(ref-344074-S11364480732009101600000) .
  3. Position the brake drum on the vehicle.
  4. Install the wheel and tire. For additional information, refer to «WHEELS & TIRES»(ref-344055) .
