Interior Lighting System: Removal & Installation Ford Escape II

Interior/illumination Lights 2 illustrations ~125 words

Removal and Installation

  1. Open the overhead console storage door to access the screws. Remove the 2 screws.
  2. Pull the overhead console down and remove the console from the headliner retainer. Disconnect the electrical connector.
  3. To install, reverse the removal procedure.

Scheme 25

Scheme 25: Ambient Lighting Module
Scheme 25: Ambient Lighting Module
ItemPart NumberDescription
1W701679Ambient lighting module screws (2 required)
2Ambient lighting module electrical connector (part of 14D375)
313C788Ambient lighting module

ITEM DESCRIPTION

  1. Remove the center console finish panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-344092) .
  2. Remove the 2 screws and the ambient lighting module. Disconnect the electrical connector.
  3. To install, reverse the removal procedure.

Scheme 26

Scheme 26: Ambient Lighting Switch
Scheme 26: Ambient Lighting Switch
ItemPart NumberDescription
1045A76Floor console finish panel
2Ambient lighting switch electrical connector (part of 14D375)
3Ambient lighting switch

ITEM DESCRIPTION

  1. Remove the floor console finish panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-344092) . Disconnect the electrical connector.
  2. Squeeze the retaining tabs and remove the ambient lighting switch.
  3. To install, reverse the removal procedure.
