Engine Controls - Description & Operation (Except Diesel & Hybrid): Component Locations Ford Escape I facelift

VECI Decal Location

Typical location of the decal will be on the underside of the hood or the radiator support sight shield.

Decal Location

Typical location of the Vehicle Certification label is on the LH door or door post pillar.

PCM Locations

Note. For PCM Removal and Installation procedures, refer to ELECTRONIC ENGINE CONTROLS .

Scheme 17

1. Focus - passenger side behind the kick panel.
2. Five Hundred, Freestyle, Montego - engine compartment, driver side, mounted to the cowl.
3. Taurus, Sable, Freestar, Monterey - behind the glove compartment (access from the engine compartment dash panel) on the passenger side.
4. Mustang - front of engine compartment, passenger side, near fender, under the battery junction box.
5. Crown Victoria, Grand Marquis, Town Car - engine compartment, driver side, fender mounted.
6. LS, Thunderbird, Explorer, Mountaineer, Aviator - passenger side, near side cowl, behind the glove compartment.
7. Ford GT - engine compartment, driver side, behind the driver seat, quarter panel mounted.
8. Escape, Mariner, Explorer Sport Trac, Ranger - behind the instrument panel (cowl), center to both driver and passenger sides (access from the engine compartment).
9. Expedition, Navigator, F-Series, F-Super Duty - passenger side of the engine compartment, mounted to the cowl.
10. Excursion - lower dash panel on the driver side.
11. E-Series - engine compartment, driver side, near the cowl (access from the engine compartment).

104-PIN PCM POWER AND GROUNDS

Scheme 18

150-PIN PCM POWER AND GROUNDS

Scheme 19

150-PIN PCM POWER AND GROUNDS

Scheme 20

170-PIN PCM POWER AND GROUNDS

Scheme 21

190-PIN PCM POWER AND GROUNDS
