Parking Aid System: Removal & Installation Ford Escape I рестайлинг

Removal and Installation

1. Remove the RH rear quarter trim panel.
2. Disconnect the electrical connectors.
3. Remove the 2 screws and the parking aid module.
4. To install, reverse the removal procedure.

Scheme 22

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-232183) .
2. Remove the rear bumper cover. For additional information, refer to «BUMPERS»(ref-232256) .
3. Press the retaining tabs and remove the parking aid sensor. Disconnect the electrical connector.
4. To install, reverse the removal procedure.

Scheme 23

1. Remove the instrument panel center finish panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-232249) .
2. Press the retaining tabs and remove the parking aid switch.
3. To install, reverse the removal procedure.
