GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Brake pad minimum thickness | 3.0 mm (0.118 inch) |
| Brake pad maximum thickness variation (pad-to-pad) | 2.0 mm (0.079 inch) |
| Brake pad maximum taper wear (in any direction) | 3.0 mm (0.118 inch) |
| Brake disc minimum thickness (disc-drum system) | 22 mm (0.86 inch) |
| Brake disc minimum thickness to machine (disc-drum system) | 22.6 mm (0.88 inch) |
| Brake disc minimum thickness (4-wheel disc brake system) | 24 mm (0.95 inch) |
| Brake disc minimum thickness to machine (4-wheel disc brake system) | 24.6 mm (0.97 inch) |
| Lubricant | |
| High Performance DOT 3 Motor Vehicle Brake Fluid PM-1 (Canada CPM-1) | ESA-M6C25-A |
| High Temperature Nickel Anti-Seize Lubricant XL-2 (Canada CXG-2) | ESE-M12A4-A |
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
| Brake Parts Cleaner PM-4 | |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Brake caliper anchor plate bolts | 150 |
| Bleeder screw | 16 |
| Brake caliper guide bolts (disc-drum system) | 35 |
| Brake caliper guide bolts (4-wheel disc brake system) | 45 |
| Brake caliper jounce hose (at caliper) | 20 |
| Brake line fitting nut | 15 |
TORQUE SPECIFICATIONS
The front disc brake system includes the brake caliper, the disc brake pads, the anchor plate, and the brake disc. The brake caliper is a single piston floating design. The brake caliper is mounted to the anchor plate by the caliper guide bolts. The brake caliper slides, or floats, on the caliper guide bolts. The disc brake is a cast, ventilated type disc. When mechanical force is applied by the driver to the brake pedal, the force is converted into hydraulic pressure by the master cylinder. The hydraulic force is directed to the disc brake calipers and transferred to the brake pads. The brake pads are then forced against the brake friction surfaces by the brake caliper pistons. The friction of the brake pads on the brake disc causes the slowing of wheel rotation and the vehicle.
For additional information, refer to BRAKE SYSTEM-GENERAL INFORMATION .
Scheme 1
- For additional information, refer to the procedures in this article.
See also:
• JACKING AND LIFTING
