HVAC System - Control Components: Removal & Installation Ford Escape I рестайлинг

Manual HVAC System 8 illustrations ~380 words

Removal and Installation

  1. Remove the RH A-pillar lower trim panel.
  2. Disconnect the blower resistor electrical connector.
  3. Remove the 2 screws and the blower motor resistor.
  4. To install, reverse the removal procedure.

Scheme 1

Scheme 1: Blower Motor Switch
  1. Remove the instrument panel center finish panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-232249) .
  2. Remove the blower motor switch knob.
  3. Press the tabs simultaneously and remove the blower motor switch.
  4. To install, reverse the removal procedure.

Scheme 2

Scheme 2: Climate Control Assembly
  1. Remove the instrument panel center finish panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-232249) .
  2. Remove the 4 screws and the climate control assembly.
  3. To install, reverse the removal procedure.

Scheme 3

Scheme 3: Function Selector Switch
  1. Remove the instrument panel center finish panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-232249) .
  2. Remove the function selector switch knob.
  3. Press the tabs simultaneously and remove the function selector switch.
  4. To install, reverse the removal procedure.

Scheme 4

Scheme 4: Recirculation Blend Door Actuator
  1. Remove the instrument panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-232249) .
  2. Disconnect the recirculation vacuum control motor vacuum supply hose.
  3. Remove the 2 recirculation vacuum control motor screws.
  4. Rotate the vacuum control motor until it clears the retaining arm and remove the vacuum control motor.
  5. To install, reverse the removal procedure.

Scheme 5

Scheme 5: Temperature Blend Door Actuator
  1. Lower the glove compartment door.
  2. Turn the temperature selector to the full cold position.
  3. Release the locking tab and remove the temperature blend door actuator from the blend door shaft.
  4. Remove the instrument panel center finish panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-232249) .
  5. Remove the temperature blend door actuator.
  6. To install, reverse the removal procedure.

Scheme 6

Scheme 6: Temperature Control Switch

Scheme 7

Scheme 7: Removal and Installation
  1. Remove the instrument panel center finish panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-232249) .
  2. Remove the temperature selector switch knob.
  3. Remove the temperature selector switch screw.
  4. Press the tab and rotate the temperature selector switch counterclockwise. Remove the temperature selector switch.
  5. To install, reverse the removal procedure. Place the temperature selector switch in the full cold position before installation.

Scheme 8

Scheme 8: Vacuum Control Motor
  1. Disconnect the vacuum supply hose from the vacuum control motor.
  2. Remove the 2 vacuum control motor screws. Rotate the vacuum control motor until it clears the retaining arm and remove the vacuum control motor.
  3. To install, reverse the removal procedure.
