Sunroof: Removal & Installation Ford Escape I

Removal and Installation

Passenger side

Scheme 1

Scheme 2

1. Remove the headliner.
2. Disconnect the roof opening panel rear drain hose.
3. Remove the roof opening panel rear drain hose. Disconnect the roof opening panel rear drain hose from the roof opening panel frame. Remove the roof opening panel rear drain hose. Remove the tape securing the roof opening panel drain hose.
4. To install, reverse the removal procedure.

Scheme 3

1. Open the roof opening panel.
2. Remove the roof opening panel frame. For additional information, refer to «Roof Opening Panel Frame»(ref-178445-S21227305952005061500000) .
3. Remove the air deflector. Lift up the air deflector and slide the air deflector to the rear to release the air deflector arms.
4. To install, reverse the removal procedure.

Scheme 4

1. Remove the headliner.
2. Remove the roof opening panel module. Disconnect the electrical connector. Remove the screw Remove the roof opening panel module.
3. To install, reverse the removal procedure.
