Seat System: Other Ford Escape I

Seats

The seats consist of the following components

1. seat track
2. seat track with height adjuster (driver)
3. power seat track (driver)
4. seat control switch
5. lumbar support (driver)
6. outboard seat cushion side shields
7. inboard seat cushion side shields
8. side air bags
9. safety belt pretensioners
10. front seat backrests
11. front seat cushions
12. 40% rear seat cushion
13. 60% rear seat cushion
14. 40% rear seat backrest
15. 60% rear seat backrest
16. bench rear seat backrest
17. bench rear seat cushion
18. rear seat backrest latches
19. rear seat headrests
20. headrest guide posts
21. rear seat side trim panels
22. rear seat backrest recliners (if equipped)
23. front seat storage drawer

The seat options consist of

1. high back bucket (leather, power, driver lumbar, dual map pockets, optional side air bag)
2. high back bucket (high series cloth, driver lumbar, dual map pockets, driver height adjuster, optional side air bags)
3. high back bucket (low series cloth, optional side air bag)
4. low back bucket (high series cloth, driver lumbar, optional passenger seat trays, optional side air bag)
5. bench rear seat (low series cloth, seatback dump latch)
6. 60/40 rear seat (high series cloth, seatback dump latch, backrest recliners)
7. 60/40 rear seat (leather, seatback dump latch, backrest recliners)

Side Air Bag

Driver and passenger side air bags are attached to the seat backrest frame. For diagnostic information or if the side air bag has been deployed, refer to AIR BAG RESTRAINT SYSTEMS .

Front seat trim covers installed on seats with side air bags cannot be repaired. The front seat backrest trim covers are to be installed new. Cleaning is permissible.

Scheme 18

Scheme 19

1. Verify the customer concern by operating the power seat. If a side air bag deployment took place, install a new seat back pad, trim cover and side air bag module. Install a new seat back frame if necessary.
2. Visually inspect for obvious signs of mechanical and electrical damage. (Scheme 19)

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

All Vehicles

Scheme 27

40% Rear Seat Backrest

60% Rear Seat Backrest

Scheme 28

1. Remove the rear seat backrest. Remove the two nuts and two bolts. Remove the rear seat backrest.
2. To install, reverse the removal procedure.

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. Remove the rear seat backrest. See «REAR SEAT BACKREST - SPLIT BENCH»(ref-176897-S34373212782005051600000) or «REAR SEAT BACKREST - BENCH»(ref-176897-S18477741302005051600000) .
2. Remove the rear seat backrest side trim panel.
3. Remove the rear seat backrest latch. Remove the bolt. Remove the nut. Remove the latch.
4. To install, reverse the removal procedure.

Scheme 35

Scheme 36

Vehicles With Side Air Bag

Scheme 37
