Engine - 3.0L (4V): Specifications Ford Escape I

Mechanical 30 illustrations ~626 words

General Specifications

ItemSpecification
SAE 5W-20 Premium Synthetic Blend Motor Oil XO -5W20-QSPWSS-M2C153-H
Silicone Gasket and Sealant F7AZ-19554-EAWSE-M4G323-A4
Metal Surface Cleaner F4AZ-19A536-RAWSE-M5B392-A
Silicone Brake Caliper Grease and Dielectric Compound D7AZ-19A221-AESE-M1C171-A

GENERAL SPECIFICATIONS

ItemSpecification
Displacement3.0L (4V) (182 CID)
No. cylinder6
Bore/stroke89.0 x 79.5 (3.5 x 3.13 in)
Fire order1-4-2-5-3-6
Oil pressure (Minimum at 1,500 RPM with engine warmed up after 10 minutes of idling.)76 kPa (11 psi)
Spark plugAWSF-32F (F35E-12405-EA) Gap = 1.30-1.40 (.052-0.56 inch)
Cylinder Head/Valve Train
Cylinder head flatness(1)
Combustion chamber volume52 cc (3.17 CI)
Valve seat width - intake1.1-1.4 mm (0.043-0.055 in)
Valve seat width - exhaust1.4-1.7 mm (0.055-0.066 in)
Valve seat angle44.75 degrees
Valve seat runout (T.I.R.)0.04 mm (0.001 in)
Valve Arrangement (Front to Rear)
LH intakeS-P-S-P-S-P
LH exhaustE-E-E-E-E-E
RH intakeP-S-P-S-P-S
RH exhaustE-E-E-E-E-E
Valve stem guide clearance Intake0.020-0.069 mm (0.0007-0.0027 in)
Exhaust0.045-0.094 mm (0.0017-0.037 in)
Valve head diameter Intake35 mm (1.38 in)
Exhaust30 mm (1.18 in)
Gauge diameter31 and 24.5 mm (1.22 and 0.96 in)
Valve face runout (limit)0.05 mm (0.001 in)
Valve face angle45.5 degrees
Valve stem diameter (std) Intake5.975-5.995 mm (0.2350-0.2358 in)
Exhaust5.950-5.970 mm (0.2343-0.2350 in)
Valve spring compression pressure Intake (n @ spec. length)680 N @ 30.19 mm (153 lbs @ 1.18 in)
Exhaust (n @ spec. length)680 N @ 30.19 mm (153 lbs @ 1.18 in)
Valve spring free length (approximate) Intake46.8 mm (1.84 in)
Exhaust46.8 mm (1.84 in)
Valve spring installed pressure (n @ spec. length) Intake228 N @ 39.99 mm (51 lbs @ 1.57 in)
Exhaust228 N @ 39.99 mm (51 lbs @ 1.57 in)
Valve springs installed pressure (n @ spec. length - service limit)10% Pressure loss @ 30.09
Valve springs - out of square limit1%
Roller follower ratio1.8:1
Hydraulic Valve Tappet
Diameter (std)16-15.988 mm (0.6290 -0.6294 in)
Clearance to bore0.018-0.069 mm (0.0007-0.0027 in)
Service limit0.016 mm (0.0006 in)
Hydraulic leakdown rate (2)5-25 seconds
Collapsed valve tappet gap-desired0.50-1.11 mm (0.019-0.043 in)
Camshaft
Lobe lift Intake (primary)4.79 mm (0.188 in)
Intake (secondary)4.79 mm (0.188 in)
Exhaust4.79 mm (0.188 in)
Lobe lift - allowable lift loss0.76 mm (0.03 in)
Valve lift @ zero lash Intake (primary)9.80 mm (0.388 in)
Intake (secondary)9.80 mm (0.388 in)
Exhaust9.80 mm (0.388 in)
Camshaft end play0.027-0.190 mm
Standard0.025-0.165 mm (0.001-0.0064 in)
Service limit0.190 mm (0.00748 in)
Journal-to-bearing clearance Standard0.025-0.076 mm (0.001-0.0029 in)
Service limit0.121 mm (0.0047 in)
Journal diameters (all)26.962-26.936 mm (1.061-1.060 in)
Journal inside diameter (cap assembled)27.012-26.987 mm
Bearing inside diameter (all)27.012-26.987 mm (1.063-1.062 in)
Cylinder Block
Head gasket surface flatness0.50 mm (0.02 in) for 150 x 150 mm (5 x 5 in) area 0.25 mm (0.01 in) for 25 x 25 mm (1 x 1 in) area 0.120 mm (0.005 in) overall
Head gasket thickness1.0 mm (0.40 in)
Main bearing bore diameter67.998 -68.022 mm (2.677-2.6780 in)
Cylinder bore Diameter(3)
Out-of-round limit0.015 mm (0.00059 in)
Out-of-round service limit0.020 mm (0.00079 in)
Taper service limit0.020 mm (0.00079 in)
Crankshaft
Main bearing journal diameter62.968-62.992 mm (2.479-2.480 in)
Connecting rod journal diameter49.970-49.990 mm (1.967-1.968 in)
Crankshaft free end play0.110-0.232 mm (0.004-0.009 in)
Crankshaft runout to rear face of cylinder block0.050 mm (0.001 in)
Connecting rod bearings Clearance to crankshaft0.028-0.066 mm (0.001-0.0025 in)
Bearing wall thickness (std) (4)1.503 mm (0.059 in)
Main bearings Clearance to crankshaft - desired0.025-0.045 mm (0.0009-0.0017 in)
Clearance to crankshaft - allowable0.025-0.050 mm (0.0009-0.0019 in)
Bearing wall thickness - grade 12.497 mm (0.0983 in)
Bearing wall thickness - grade 22.501 mm (0.0985 in)
Bearing wall thickness - grade 32.505 mm (0.0986 in)
Connecting Rod
Piston pin bore diameter21.017-21.031 mm (0.827-0.828 in)
Crankshaft bearing bore diameter53.015 -53.035 mm (2.0872-2.0879 in)
Length (center to center)138.06-138.14 mm (5.435-5.438 in)
Alignment (bore to bore max difference) (5) Twist0.050 mm per 25 (0.0019 per 0.984 in)
Bend0.038 mm per 25 (0.0014 per 0.984 in)
Side clearance (assembled to crank) Standard0.100-0.30 mm (0.0039-0.0118 in)
Service limit0.35 mm (0.0013in) max
Piston
Piston diameter Coated grade 1(6) 88.990 -89.010 mm (3.5035-3.5043 in)
Coated grade 288.998 -89.022 mm (3.5039-3.5048 in)
Coated grade 389.010 -89.030 mm (3.5043-3.5051 in)
Uncoated grade 188.970 -88.980 mm (3.50275-3.50314 in)
Uncoated grade 288.978 -88.992 mm (3.50306-3.50362 in)
Uncoated grade 389.010 -89.030 mm (3.50432-3.50511 in)
Piston-to-bore clearance0.012 to 0.022 mm (0.0005 -0.0009 in)
Pin bore diameter (piston)21.008 -21.012 mm (0.8270-0.8272 in)
Ring groove width Compression (top)1.230-1.245 mm (0.0484-0.0490 in)
Compression (bottom)1.530-1.545 mm (0.0602-0.0608 in)
Oil ring3.030-3.055 mm (0.1192-0.1203 in)
Piston pin Length60.51-60.08 mm (2.382 -2.365 in)
Diameter21.011 -21.013 mm (0.0013 in)
Pin-to-piston clearance0.005 to +0.001 mm (0.0001-0.00003 in)
Pin-to-rod clearance Standard0.004-0.020 mm (0.0001-0.0007 in)
Service limit0.035 mm (0.0013 in)
Piston Ring-To-Groove Clearance Compression (top)0.040-0.075 mm (0.0015-0.0029 in)
Piston Ring-To-Groove Clearance Compression (bottom)0.040-0.085 mm (0.0015-0.0033 in)
Oil ringSnug Fit
Piston ring gap (7) Compression (top) - gauge diameter0.100-0.250 mm (0.0039-0.0098 in)
Compression (bottom) - gauge diameter0.27-0.42 mm (0.0106-0.0165 in)
Oil ring (steel rail) - gauge diameter0.15-0.65 mm (0.0059-0.0255 in)
Compression (top) - service limit0.50 mm (0.0196 in) max
Compression (bottom) - service limit0.65 mm (0.0255 in) max
Oil ring (steel rail) - service limit0.90 mm (0.0354 in) max
Lubrication System
Oil capacity (8)5.5 Quarts 5.2 Liters
Drive Belt Tension
NOTE: Drive belts have different tension specifications depending on whether they are newly installed(9)
Drive belt type 6 rib front end accessory driveAutomatic Tensioners
(1) Refer to the procedure for specifications. (2) Time required for plunger to leak down 1.6 mm (0.063 in) of travel with 222 N force and leak down fluid in tappet. (3) Cylinder Bore Diameter Grade 1: 89.000-89.010 mm (3.50394-3.50433 inch) Grade 2: 89.010-89.020 mm (3.50433-3.50472 inch) Grade 3: 89.020-89.030 mm (3.50472-3.50512 inch) (4) 0.250 mm (0.00984 in) Undersize - Add 0.125 mm (0.00492 in) to standard or grade 2 thickness. (5) Pin bore and crank bearing bore must be parallel and in same vertical plane within the specified total difference when measured at the ends of a 203.0 mm (7.9921 in) bar, 101.5 mm (3.9960 in) on each side of rod centerline. (6) Measured at 50 mm (1.9685 in) from outer perimeter top of piston to the pin axis. (7) Specification 82.4 mm (3.2441 inch) diameter gauge. (8) With filter change. (9) Newly installed refers to the condition of the "new" drive belt before the engine has made no more than one rotation and before the drive belt has had a chance to stretch or seat into the pulley grooves.
NOTE
Drive belts have different tension specifications depending on whether they are newly installed
(1)Refer to the procedure for specifications.
(2)Time required for plunger to leak down 1.6 mm (0.063 in) of travel with 222 N force and leak down fluid in tappet.
(3)Cylinder Bore Diameter
(4)0.250 mm (0.00984 in) Undersize - Add 0.125 mm (0.00492 in) to standard or grade 2 thickness.
(5)Pin bore and crank bearing bore must be parallel and in same vertical plane within the specified total difference when measured at the ends of a 203.0 mm (7.9921 in) bar, 101.5 mm (3.9960 in) on each side of rod centerline.
(6)Measured at 50 mm (1.9685 in) from outer perimeter top of piston to the pin axis.
(7)Specification 82.4 mm (3.2441 inch) diameter gauge.
(8)With filter change.
(9)Newly installed refers to the condition of the "new" drive belt before the engine has made no more than one rotation and before the drive belt has had a chance to stretch or seat into the pulley grooves.

GENERAL SPECIFICATIONS

Torque Specifications

DescriptionNmLb-ftLb-in
A/C compressor bolts2518
A/C compressor bracket bolts(1)
A/C line nut87
A/C to water pump bracket bolts2518
Accessory drive belt tensioner bolt2518
Camshaft cap bolts1089
Camshaft oil seal retainer bolts108
Camshaft position sensor bolt1089
Cooler tube bracket bolt2818
Crankshaft damper bolt(1)
Crankshaft position sensor bolt1089
Crankshaft pulley(1)
Crankshaft pulley bracket nuts2518
Cylinder head bolts(1)
Exhaust gas recirculation (EGR) tube nuts4030
EGR valve bolts2518
EGR valve nuts(1)
Engine front cover bolts and studs(1)
EGR vacuum regulator tube nuts653
Exhaust bracket nut4030
Flexplate bolts8059
Ball joint nuts8059
Front splash shield bolts762
Fuel charging harness nut653
Fuel rail bolts1089
Generator bolts and studs4835
Ground strap bolt1511
Halfshaft nuts258191
Halfshaft bracket bolts4835
Heater hose bracket nuts762
Ignition coil-on-plug bolts653
Knock sensor bolt1813
LH engine support insulator bolts7052
LH engine support insulator nut9066
LH exhaust manifold nuts2015
Lower cylinder block bolts and studs(1)
Lower intake manifold bolts1089
Motor mount bracket bolts/nuts10376
Oil level indicator and tube stud1089
Oil pan baffle nuts(1)
Oil pan bolts and studs2518
Oil pan to transaxle bolts4030
Oil pressure sensor1410
Oil pump bolts1089
Oil pump screen and pickup tube bolts(1)
Oil separator bolts1089
Outer tie rod end nuts5541
Power steering pump bolts2518
Power steering pressure tube bracket nut1089
Power steering pressure tube nut3727
Powertrain control module (PCM) electrical connector bolt653
Power distribution box cable nuts129
Radiator fan bolt1089
RH engine support insulator nut9066
RH engine support insulator through bolt and nut12089
RH exhaust manifold nuts2015
RH radio ignition interference capacitor nut1089
Shifter cable nut1713
Starter motor ground cable bolt2518
Starter cable positive nut129
Steering shaft pinch bolt4030
Strut to knuckle bolts11585
Subframe bolts200148
Subframe nuts150111
Transaxle mount bolts5541
Transaxle mount through bolt9066
Sway bar end link nuts4835
Throttle body bolt and stud1089
Timing chain guide bolts2518
Timing chain tensioner bolts2518
Torque converter-to-flexplate nuts4030
Transaxle-to-oil pan bracket bolt2518
Transaxle-to-oil pan bracket nuts1089
Upper intake manifold bolts1089
Valve cover bolts and studs1089
Water pump bolts2518
Wire harness bolt544
Y-pipe nuts4030
Y-pipe-to-exhaust manifold nuts4030
(1) Multiple step sequence. See procedure.
(1)Multiple step sequence. See procedure.

TORQUE SPECIFICATIONS

The 3.0L Duratec is a four-valve-per-cylinder, dual overhead camshaft engine. The engine uses a distributorless ignition system with a separate coil located above each spark plug. The cylinder block is a two-piece design with the upper portion housing the cylinders, and a separate lower cylinder block containing the main bearing caps. Both sections are made of aluminum, with inserts for the bearing areas and caps. An aluminum oil pan bolts to the bottom of the lower cylinder block and to the transaxle to provide greater strength.

The camshafts are mounted in the cylinder heads and act against a roller follower to open and close the valves. A hydraulic lash adjuster is located on one side of the roller follower and the valve tip on the opposite end. The camshafts are driven off the front of each cylinder head by two chains (one each side). Both of the chains are driven by a single sprocket that is located on the crankshaft, just in front of the oil pump.

Scheme 74

Scheme 74: Upper Engine Components
Scheme 74: Upper Engine Components

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76: Lower Engine Components
Scheme 76: Lower Engine Components

Scheme 77

Scheme 77
Scheme 77

Refer to ENGINE SYSTEM - GENERAL INFORMATION for basic mechanical concerns. Refer to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV for driveability concerns.

Scheme 78

Scheme 78: Removal
Scheme 78: Removal

Scheme 79

Scheme 79
Scheme 79

Scheme 80

Scheme 80
Scheme 80

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87

Scheme 88

Scheme 88
Scheme 88

Scheme 89

Scheme 89
Scheme 89

Scheme 90

Scheme 90
Scheme 90
  1. Remove the air cleaner outlet tube. Remove the crankcase ventilation tube. Loosen the clamps. Remove the air cleaner outlet tube.
  2. Remove the three nuts and the engine appearance cover.
  3. Disconnect the cables. Disconnect the throttle cable. If equipped, disconnect the speed control cable. Remove the throttle cable bracket bolts.
  4. Disconnect the throttle position (TP) sensor and idle air control (IAC) electrical connectors.
  5. Disconnect the exhaust gas recirculation (EGR) valve vacuum hose and EGR tube nut.
  6. Disconnect the EGR vacuum regulator solenoid electrical connector and vacuum hose.
  7. Disconnect the three vacuum hoses on the back of the intake manifold. Disconnect the chassis vacuum hose. Disconnect the engine vacuum hose. Disconnect the positive crankcase ventilation (PCV) hose.
  8. Disconnect the vapor management valve (VMV) vacuum hose.
  9. Disconnect the two electrical connectors attached to the left side of the upper intake manifold.
  10. Disconnect the power steering pressure (PSP) sensor electrical connector.
  11. Remove the bolt and position the transmission vent hose and bracket aside.
  12. Remove the nut from the wire harness.
  13. Remove the eight bolts and the upper intake manifold. Remove and discard the gaskets. Clean all sealing surfaces.

Scheme 91

Scheme 91: Installation
Scheme 91: Installation

Scheme 92

Scheme 92
Scheme 92

Scheme 93

Scheme 93
Scheme 93

Scheme 94

Scheme 94
Scheme 94

Scheme 95

Scheme 95
Scheme 95

Scheme 96

Scheme 96
Scheme 96

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99

Scheme 100

Scheme 100
Scheme 100

Scheme 101

Scheme 101
Scheme 101

Scheme 102

Scheme 102
Scheme 102

Scheme 103

Scheme 103
Scheme 103
  1. Install new gaskets in the upper intake manifold.
  2. Position the upper intake manifold and tighten the bolts in the sequence shown.
  3. Connect the PSP electrical connector.
  4. Position the transmission vent tube and bracket and install the bolt.
  5. Position the wire harness and install the nut.
  6. Install the two electrical connectors on the left side of the intake manifold.
  7. Install the vapor management valve (VMV) vacuum hose.
  8. Connect the three vacuum hoses on the back of the upper intake manifold. Connect the chassis vacuum hose. Connect the engine vacuum hose. Connect the PCV hose.
  9. Connect the EGR vacuum regulator solenoid electrical connector and the vacuum hose.
  10. Install the EGR valve vacuum hose and EGR tube nut.
  11. Connect the TP sensor and IAC electrical connectors.
  12. Connect the throttle cables. Install the throttle cable bracket bolts. Connect the throttle cable. If equipped, connect the speed control cable.
  13. Install the air cleaner outlet tube. Position the air cleaner outlet tube. Install the hoses. Install the clamps.
  14. Install the engine appearance cover.

More articles — Engine - 3.0L (4V)
