General Specifications
| Item | Specification |
|---|---|
| Brake Pedal | |
| Pedal free play mm (in) | 7.8 -12 (0.3-0.47) |
| Brake Pads/Shoes | |
| Brake pad minimum thickness | 3.0 mm (0.118 inch) |
| Brake pad maximum thickness variation (pad-to-pad) | 2.0 mm (0.079 inch) |
| Brake pad maximum taper wear (in any direction) | 3.0 mm (0.118 inch) |
| Brake shoe minimum thickness | 1.0 mm (0.03 inch) |
| Brake Disc/Drum | |
| Brake disc minimum thickness | 22.0 mm (0.86 inch) |
| Brake disc minimum thickness to machine | 22.6 mm (0.88 inch) |
| Brake drum maximum inside diameter | 230.1 mm (9.05 inch) |
| Lubricant | |
| High Performance DOT 3 Motor Vehicle Brake Fluid PM-1 (Canada CXC-31) | ESA-M6C25-A (United States and Canada only) |
| High Temperature Nickel Anti-Seize Lubricant XL-2 (Canada CXG-2-B) | ESE-M12A4-A |
| Silicone Brake Caliper Grease and Dielectric Compound XG-3 | ESE-M1C171-A |
| Brake Parts Cleaner PM-4 | |
GENERAL SPECIFICATIONS
Torque Specifications
| Description | Nm |
|---|---|
| Brake line master cylinder fittings | 15 |
| Disc brake caliper bleeder screws | 16 |
| Wheel cylinder bleeder screws | 8 |
TORQUE SPECIFICATIONS
This article is an overview of the complete brake system.
For more information on rear brake operation, refer to DESCRIPTION & OPERATION .
For more information on front disc brake operation, refer to DESCRIPTION & OPERATION .
For more information on parking brake operation, refer to DISC & DRUM .
For more information on hydraulic brake actuation, refer to DISC & DRUM .
For more information on power brake actuation, refer to DISC & DRUM .
For more information on the anti-lock brake system, refer to ANTI-LOCK CONTROL .
