Interior Lighting System: Diagnosis Ford Escape I

Interior/illumination Lights 25 illustrations ~375 words

Inspection and Verification

  1. Verify the customer concern by operating the system.
  2. Visually inspect for obvious signs of mechanical and electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Damaged components Central junction box (CJB) fuse 27 (10A) Wiring harness Loose, damaged or corroded connectors Interior map lamp, dome lamp, cargo lamp
  3. If an obvious cause for an observed of reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the diagnostic tool does not power up, refer to the .
  5. Carry out the DATA LINK DIAGNOSTICS test. If the diagnostic tool responds with: CKT914, CKT915 or CKT70 = ALL ECUS NO RESP/NOT EQUIP, refer to «MODULE COMMUNICATIONS NETWORK»(ref-177213) . NO RESP/NOT EQUIP for GEM, Refer to «MULTIFUNCTION ELECTRONIC MODULE»(ref-204647) . SYSTEM PASSED, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs, and carry out the self-test diagnostics for the GEM.
  6. If the DTCs retrieved are related to the concern, go to the GEM Diagnostic Trouble Code (DTC) Index to continue diagnostics. See «GEM DIAGNOSTIC TROUBLE CODE INDEX»(ref-204641-S08394246912005111200000) .
  7. If no DTCs related to the concern are retrieved, proceed to the Symptom Chart to continue diagnostics.
  8. If the DTCs are retrieved that are not found in the following GEM Diagnostic Trouble Code (DTC) Index, refer to «MULTIFUNCTION ELECTRONIC MODULE»(ref-204647) .

GEM Diagnostic Trouble Code (DTC) Index

DTCDescriptionSourceAction
B1317Battery Voltage HighGEMGO to PINPOINT TEST F .
B1318Battery Voltage LowGEMGO to PINPOINT TEST F .
B1319Driver Door Ajar Circuit FailureGEMGO to PINPOINT TEST B .
B1327Passenger Door Ajar Circuit FailureGEMGO to PINPOINT TEST B .
B1331Decklid Ajar Rear Door Circuit FailureGEMGO to PINPOINT TEST B .
B1335Door Ajar RR Circuit FailureGEMGo To PINPOINT TEST B .
B1371Illuminated Entry Relay Circuit FailureGEMIf the interior lamps are inoperative, GO to PINPOINT TEST A . If the interior lamps stay on continuously/do not fade out, GO to PINPOINT TEST B .
B1571Door Ajar LR Circuit FailureGEMGo To PINPOINT TEST B .
All other DTCsGEMREFER to MULTIFUNCTION ELECTRONIC MODULE .

GEM DIAGNOSTIC TROUBLE CODE (DTC) INDEX

Symptom Chart

ConditionPossible SourcesAction
No communication with the generic electronic module (GEM)Central junction box (CJB) fuse 27 (10A). Circuitry. GEM.REFER to MULTIFUNCTION ELECTRONIC MODULE .
The interior lamps are inoperativeCircuitry. Dome/cargo lamp. GEM.GO to PINPOINT TEST A .
The interior lamps stay on continuously do not fade outCircuit. Map/dome lamp switch. GEM.GO to PINPOINT TEST B .
The interior lamps do not turn on with one door openCircuit. Door/liftgate ajar switch. GEM.GO to PINPOINT TEST C .
The illuminated entry is inoperative when using the remote transmitterRemote transmitter. GEM.GO to PINPOINT TEST D .
The demand lighting is inoperativeCircuitry. Dome/map lamp. GEM.GO to PINPOINT TEST E .
An individual interior lamp is inoperativePower supply. Ground. Bulb.REPAIR as necessary.
An individual demand lamp is inoperativePower supply. Ground. Bulb.REPAIR as necessary.
Battery voltage out of rangeCircuitry. GEM. Charging system.GO to PINPOINT TEST F .

SYMPTOM CHART

Scheme 1

Scheme 1: PINPOINT TEST A: THE INTERIOR LAMPS ARE INOPERATIVE

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4: PINPOINT TEST B: THE INTERIOR LAMPS STAY ON CONTINUOUSLY - DO NOT FADE OUT

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16: PINPOINT TEST C: THE INTERIOR LAMPS DO NOT TURN ON WITH ONE DOOR OPEN

Scheme 17

Scheme 17

Scheme 18

Scheme 18: PINPOINT TEST D: THE ILLUMINATED ENTRY IS INOPERATIVE WHEN USING THE REMOTE TRANSMITTER

Scheme 19

Scheme 19: PINPOINT TEST E: THE DEMAND LIGHTING IS INOPERATIVE

Scheme 20

Scheme 20

Scheme 21

Scheme 21: PINPOINT TEST F: BATTERY VOLTAGE OUT OF RANGE

Scheme 22

Scheme 22: Removal and Installation

Scheme 23

Scheme 23
  1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-204629) .
  2. Remove the interior/map reading lamp lens.
  3. Remove the interior/map reading lamp assembly. Remove the screws. Remove the interior/map reading lamp. Disconnect the electrical connector.
  4. To install, reverse the removal procedure.

Scheme 24

Scheme 24: Removal and Installation

Scheme 25

Scheme 25
  1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-204629) .
  2. Remove the cargo lamp assembly from the headliner.
  3. Remove the cargo lamp assembly. Disconnect the electrical connectors. Remove the cargo lamp assembly.
  4. To install, reverse the removal procedure.
