Steering Column Switches: Diagnosis — Ford Escape I (2000-2004)

Steering Column Switches: Diagnosis Ford Escape I

Inspection and Verification

Verify the customer concern by operating the ignition switch and the multifunction switch.
Visually inspect the ignition switch and the steering column multifunction switch for damage; refer to the following chart: Visual Inspection Chart VISUAL INSPECTION CHART Mechanical Electrical Ignition switch Turn signal switch (part of the steering column multifunction switch) Hazard flasher switch Wiper/washer switch Connections Battery junction box (BJB) fuse MAIN (120A) 19 (40A) 20 (40A) Central junction box (CJB) fuse IG KEY 11 (10A) Circuitry
If binding occurs, turn the steering wheel left or right to release any pressure on the ignition switch and make sure the ignition key is cut correctly.
If the cause of the switch concern is not visually evident, proceed to the Symptom Chart.

Symptom Chart

Condition	Possible Sources	Action
The ignition switch is inoperative No power in ACC	Battery junction box (BJB) fuse MAIN (120A). BJB fuse 19 (40A). Central junction box (CJB) fuse 11 (10A). Ignition switch. Circuitry. Battery. Battery junction box (BJB) fuse 2 (40A). Ignition switch. ACC relay. Circuitry.	GO to PINPOINT TEST A . GO to PINPOINT TEST B .
No power in ON	Ignition switch. IGN relay. Circuitry.	GO to PINPOINT TEST C .
No power in START	Ignition switch. Circuitry.	GO to PINPOINT TEST D .
The ignition switch is inoperative-key cannot be removed from ignition switch (automatic transmission only)	Ignition switch. Shift lock module. Circuitry.	GO to PINPOINT TEST E .
The ignition switch is inoperative-key can be removed from ignition switch with transmission in gear (automatic transmission only)	Ignition switch. Shift lock module. Circuitry.	GO to PINPOINT TEST F .

SYMPTOM CHART

Scheme 2

Scheme 2: PINPOINT TEST A: THE IGNITION SWITCH IS INOPERATIVE

Scheme 3

Scheme 3: PINPOINT TEST B: NO POWER IN ACC

Scheme 4

Scheme 5

Scheme 5: PINPOINT TEST C: NO POWER IN ON

Scheme 6

Scheme 7

Scheme 7: PINPOINT TEST D: NO POWER IN START

Scheme 8

Scheme 8: PINPOINT TEST E: THE IGNITION SWITCH IS INOPERATIVE-KEY CANNOT BE REMOVED FROM IGNITION SWITCH (AUTO

Scheme 9

Scheme 9: PINPOINT TEST F: THE IGNITION SWITCH IS INOPERATIVE-KEY CAN BE REMOVED FROM IGNITION SWITCH WITH TRA

Scheme 10

Scheme 10: Removal and Installation

Remove the clockspring. For additional information, refer to «AIR BAG RESTRAINT SYSTEMS»(ref-150665) .
Remove the multifunction switch. Disconnect the electrical connector. Remove the screws. Remove the multifunction switch.
To install, reverse the removal procedure.

Scheme 11

Scheme 11: Removal and Installation

Scheme 12

Disconnect the battery ground cable. For additional information refer to Section BATTERY, MOUNTING AND CABLES .
Position the instrument panel center finish panel rearward from the instrument panel.
Remove the hazard flasher switch. Disconnect electrical connector. Remove the hazard flasher switch.
To install, reverse the removal procedure.

Scheme 13

Scheme 13: Removal and Installation

Scheme 14

Scheme 15

Depower the supplemental restraint system (SRS). For additional information, refer to «AIR BAG RESTRAINT SYSTEMS»(ref-150665) .
Remove the upper steering column shroud.
Remove the lower steering column shroud. Remove the screws. Remove the lower steering column shroud.
Disconnect the ignition switch electrical connector.
Remove the ignition switch. Press the two tabs. Remove the ignition switch.
To install, reverse the removal procedure. Repower the supplemental restraint system (SRS). For additional information, refer to «AIR BAG RESTRAINT SYSTEMS»(ref-150665) .
