PCV System - 2.0L GTDI

The PCV system uses intake manifold vacuum to ventilate blow-by vapors from the crankcase and return the vapors to the intake manifold for combustion. The PCV valve varies the amount of blow-by vapors returned to the intake manifold based on available engine vacuum. The PCV valve is serviced as part of the crankcase vent oil separator.

PCV System - 3.5L/3.7L

The PCV system

1. uses intake manifold vacuum to ventilate blow-by vapors from the crankcase.
2. returns the vapors to the intake manifold for combustion.

The PCV system consists of the

1. crankcase ventilation tube.
2. PCV valve.

The PCV valve

1. varies the amount of blow-by vapors returned to the intake manifold based on available engine vacuum.
2. prevents combustion gases from backfiring into the crankcase.

Refer to the INTRODUCTION article.

Scheme 47

1. Remove the intake manifold. For additional information, refer to «ENGINE - 2.0L GTDI»(ref-494556) .
2. Remove the 8 bolts, crankcase vent oil separator and the gasket. To install, tighten to 10 Nm (89 lb-in).
3. To install, reverse the removal procedure. Inspect and replace the crankcase vent oil separator gasket as necessary.

Positive Crankcase Ventilation (PCV) Valve

MATERIAL SPECIFICATIONS

Scheme 48
