Rear View Mirror: Removal & Installation Ford Edge I рестайлинг

Installation

1. If equipped, connect the heated mirror and auto-dimming electrical connectors.
2. Position the exterior mirror glass onto the exterior mirror motor.
3. Firmly press the exterior mirror glass until it snaps onto the exterior mirror motor.
4. Rotate the exterior mirror glass in all directions after the installation to make sure that all of the exterior mirror glass retaining clips are completely fastened.

Scheme 46

1. Remove the exterior mirror glass. For additional information, refer to «EXTERIOR MIRROR GLASS»(ref-494635-S05096243292012081400000) .
2. Remove the 3 exterior mirror motor screws.
3. Disconnect the exterior mirror motor electrical connector.
4. Remove the exterior mirror motor.
5. To install, reverse the removal procedure.

Scheme 47

1. Remove the exterior mirror glass. For additional information, refer to «EXTERIOR MIRROR GLASS»(ref-494635-S05096243292012081400000) .
2. Depress the 4 tabs and remove the exterior mirror cover.
3. To install, reverse the removal procedure.

Removal and Installation

1. Remove the exterior mirror control switch. Insert a non-marring tool between the door trim panel and the exterior mirror control switch and gently pry outward.

SPECIAL TOOLS CHART Installer, Rear Mirror 501-025 (T94P-17700-AH) Mirror Remover 501-D118A Installer, Rear Mirror 501-191 Mirror Remover 501-190

Scheme 48

Scheme 49

Scheme 50

Removal

Mirror Type 1

Note. The windshield must be at room temperature. Otherwise, damage to the windshield glass may occur.

Note. A video version of this procedure is available on-line.

Mirror Type 1

Note. A video version of this procedure is available on-line.
