SPECIFICATIONS
| Item | Specification | Fill Capacity |
|---|---|---|
| Dye-Lite® ATF/Power Steering Fluid Leak Detection Dye 164-R3701 (Rotunda) | ||
| MERCON® V Automatic Transmission Fluid XT-5-QM (or XT-5-QMC) (US); CXT-5-LM12 (Canada) | MERCON® V |
MATERIAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Power Steering Gear | |
| Turning effort | 35 N (7.86 lb) |
| Power Steering Pump | |
| Flow | 7.25-8.87L/min (1.91-2.34 gpm) Fluid @ 74°-80°C (165°-175°F) Engine @ 2, 000 RPM |
| Minimum capacity | 5.0L/min (1.32 gpm) Fluid @ 74°-80°C (165°-175°F) Pressure 500 kPa (725 psi) |
| Pressure | 827 kPa (120 psi) Fluid @ 74°-80°C (165°-175°F) Engine @ 2, 000 RPM |
| Relief pressure | 11.3-11.8 kPa (1, 638-1, 711 psi) |
| Power Steering Purge Vacuum | |
| Air purge vacuum | 68-85 kPa (20-25 in-Hg) |
GENERAL SPECIFICATIONS
The power steering system consists of the following components
- Power steering pump
- Fluid reservoir
- Rack and pinion steering gear
- Fluid cooler
- Power steering pressure and return lines/hoses
SPECIAL TOOLS DESCRIPTION CHART 100W/12 Volt DC UV Lamp 164-R0751 Dial Thermometer 0-220°F 023-R0007 or equivalent Evacuation Cap, Power Steering 211-265 or equivalent Vacuum Pump Kit 416-D002 (D95L-7559-A) or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Scheme 1
Scheme 2
Scheme 3
Scheme 4
| Item | Specification |
|---|---|
| Dye-Lite® ATF/Power Steering Fluid Leak Detection Dye 164-R3701 (Rotunda) | |
| MERCON® V Automatic Transmission Fluid XT-5-QM (or XT-5-QMC) (US); CXT-5-LM12 (Canada) | MERCON® V |
MATERIAL SPECIFICATIONS
