SPECIFICATIONS
| Description | Nm |
|---|
| Floor console center bolts | 6 |
| Floor console front side bolts | 6 |
| Floor console rear bolts | 6 |
| Floor console-to-instrument panel bolts | 6 |
| Front of dash bolt | 20 |
| Instrument panel-to-steering column bracket bolts | 22 |
| LH instrument panel bolts | 20 |
| LH instrument panel Torx head bolt | 30 |
| LH instrument panel-to-body bolt | 7 |
| LH instrument panel-to-floor bolts | 22 |
| RH instrument panel bolt | 22 |
| RH instrument panel-to-body bolt | 7 |
| RH instrument panel-to-floor bolt | 22 |
| Steering column shaft-to-steering column bolt | 23 |
Scheme 59
Scheme 59: Edge Instrument Panel
| Item | Part Number | Description |
|---|
| 1 | 7804481 | LH instrument panel side trim panel |
| 2 | W790178 | Clip (4 required) |
| 3 | W790178 | Clip (4 required) |
| 4 | W707628 | Instrument Panel Cluster (IPC) lower finish panel screws (2 required) |
| 5 | 78044D70 | IPC lower finish panel |
| 6 | W790178 | Clip (4 required) |
| 7 | 7804480 | RH instrument panel side trim panel |
| 8 | 7804338 | Right finish panel |
| 9 | W790178 | Clip (4 required) |
| 10 | 7804338 | Left finish panel |
| 11 | W712856 | Clip (3 required) |
| 12 | 7804459 | Steering column opening trim panel |
| 13 | W505424 | Steering column opening trim panel screw (2 required) |
| 14 | W790178 | Clip (5 required) |
| 15 | 7806200 | Glove compartment dampener |
| 16 | 7806024 | Glove compartment |
| 17 | W710506 | Glove compartment dampener screw (2 required) |
Scheme 60
Scheme 60: Edge Instrument Panel Fasteners
| Item | Part Number | Description |
|---|
| 1 | W703845 | LH instrument panel-to-body bolt |
| 2 | 14401 | LH instrument panel electrical connectors |
| 3 | 3RA27 | Steering column shaft-to-steering column bolt |
| 4 | W706246 | Instrument panel-to-floor bolt (3 required) |
| 5 | | Antenna lead-in |
| 6 | 14401 | RH instrument panel electrical connector |
| 7 | W703845 | RH instrument panel-to-body bolt |
| 8 | W712386 | LH instrument panel bolt (2 required) |
| 9 | W712387 | LH instrument panel Torx head bolt |
| 10 | W712403 | Instrument panel-to-front of dash bolt |
| 11 | W706246 | RH instrument panel bolt |
| 12 | 04320 | Instrument panel |
Scheme 61
Scheme 61: MKX Instrument Panel
| Item | Part Number | Description |
|---|
| 1 | 78044F58 | LH Instrument Panel Cluster (IPC) top cover |
| 2 | W790178 | Clip (9 required) |
| 3 | W707628 | IPC top cover screws (2 required) |
| 4 | 7804480 | RH instrument panel side trim panel |
| 5 | 7806024 | Glove compartment |
| 6 | W790178 | Clip (4 required) |
| 7 | 78044A91 | Left finish panel |
| 8 | 7804459 | Steering column opening trim panel |
| 9 | W505424 | Steering column opening trim panel screws (2 required) |
| 10 | W790178 | Clip (5 required) |
| 11 | 7804481 | LH instrument panel side trim panel |
| 12 | W790178 | Clip (6 required) |
| 13 | 7806200 | Glove compartment dampener |
| 14 | 78044E82 | Defroster grille |
| 15 | W790178 | Defroster grille clip (7 required) |
| 16 | 78044F58 | RH IPC top cover |
| 17 | W790178 | RH instrument trim panel clip (7 required) |
| 18 | 7804338 | RH instrument trim panel |
| 19 | W710506 | Glove compartment dampener screw (2 required) |
| 20 | W707628 | RH IPC top cover screw (27 required) |
Scheme 62
Scheme 62: MKX Instrument Panel Fasteners
| Item | Part Number | Description |
|---|
| 1 | W703845 | LH instrument panel-to-body bolt |
| 2 | 14401 | LH instrument panel electrical connectors |
| 3 | 3RA27 | Steering column shaft-to-steering column bolt |
| 4 | W706246 | Instrument panel-to-floor bolt (3 required) |
| 5 | | Antenna lead-in |
| 6 | 14401 | RH instrument panel electrical connector |
| 7 | W703845 | RH instrument panel-to-body bolt |
| 8 | 04320 | Instrument panel |
| 9 | W712386 | LH instrument panel bolt (2 required) |
| 10 | W712387 | LH instrument panel Torx head bolt |
| 11 | W712403 | Instrument panel-to-front of dash bolt |
| 12 | W706246 | RH instrument panel bolt |
- For additional information, refer to the appropriate procedures.
