Body System - Uni-Body, Subframe & Mounting System: Removal & Installation Ford Edge I рестайлинг

Removal

Note. Suspension and subframe fasteners are critical parts specially designed for the purpose. Replacement fasteners must be identical to the original equipment and torqued as specified. Poor quality or improperly tightened fasteners may fail in service, resulting in vehicle damage and major repair expense.

Note. When repairing the power steering system, care should be taken to prevent the entry of foreign material or failure of the power steering components may result.

Note. Removal steps in this procedure may contain installation details.

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. Steering wheel in straight ahead position. General Equipment: Steering Wheel Holder.
2. Remove the wheel and tire. For additional information, refer to «WHEELS AND TIRES»(ref-494563) .
3. Discard the specified component. Follow local disposal regulations. To install, tighten the new bolt to 25 Nm (18 lb-ft).
4. On both sides. Marker.
5. To install, tighten to 9 Nm (80 lb-in).
6. On both sides. To install, tighten to 9 Nm (80 lb-in).
7. Discard the specified component. Follow local disposal regulations. To install, tighten the new bolt to 26 Nm (19 lb-ft).
8. On both sides. Discard the specified component. Follow local disposal regulations. To install, tighten the new nuts to 48 Nm (35 lb-ft).
9. On both sides. Special Tool(s): Tie Rod End Remover 211-105 (T85M-3395-A).
10. On both sides. Discard the specified component. Follow local disposal regulations. To install, tighten the new nuts and bolts to 55 Nm (41 lb-ft).
11. Wire brush. Apply the substance from the specified tube. Material: Threadlock and Sealer TA-25. To install, tighten to 115 Nm (85 lb-in).
12. General Equipment: Powertrain Lift.
13. On both sides. Discard the specified component. Follow local disposal regulations. To install, tighten the new bolts to 90 Nm (66 lb-ft).
14. Discard the specified component. Follow local disposal regulations. To install, review the unique instructions and illustration in the installation procedure.
15. Discard the specified component. Follow local disposal regulations. To install, tighten the new nuts to 133 Nm (98 lb-ft).
16. On both sides. Discard the specified component. Follow local disposal regulations. To install, tighten the new nuts to 133 Nm (98 lb-ft).
17. General Equipment: Powertrain Lift. To install, align the subframe to the marks on the uni-body.

Scheme 20

1. To install, reverse the removal procedure.
2. Loosely install all fasteners before tightening. Tighten the new nuts to 133 Nm (98 lb-ft). Tighten the new bolts to 90 Nm (66 lb-ft).
3. Fill the power steering system. For additional Information, refer to «STEERING SYSTEM»(ref-494570) .

Subframe - Front, 3.5L and 3.7L

SPECIAL TOOLS CHART Tie-Rod End Remover 211-105 (T85M-3395-A) Powertrain Lift 300-OTC1585AE or equivalent

Scheme 21

MATERIAL SPECIFICATION

Scheme 22

Note. Suspension and subframe fasteners are critical parts because they affect performance of vital parts and systems and their failure may result in major service expense. A new part with the same part number must be installed if installation becomes necessary. Do not use a replacement part of lesser quality or substitute design. Torque values must be used as specified during reassembly to make sure of correct retention of these parts.

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. Using a suitable holding device, hold the steering wheel in the straight-ahead position.
2. Remove the wheel and tire. For additional information, refer to «WHEELS AND TIRES»(ref-494563) .
3. Remove and discard the steering column shaft-to-steering gear bolt and disconnect the steering column shaft from the steering gear. To install, tighten new bolt to 25 Nm (18 lb-ft).
4. Mark the subframe position for reference during installation.
5. Remove the 3 pin-type retainers, the 7 screws and the front splash shield.
6. Remove the pin-type retainer from the power steering return line bracket.
7. Remove the 3 RH front subframe-to-lower bumper washer-nuts. To install, tighten to 9 Nm (80 lb-in).
8. Remove the 3 LH front subframe-to-lower bumper washer-nuts and separate the bumper from the front subframe. To install, tighten to 9 Nm (80 lb-in).
9. Remove the power steering fluid cooler-to-front subframe bolt. To install, tighten to 9 Nm (80 lb-in).
10. Remove the exhaust Y-pipe. For additional information, refer to «EXHAUST SYSTEM»(ref-494567) .
11. Remove and discard the 2 outer tie-rod-end cotter pins and nuts. To install, tighten to 48 Nm (35 lb-ft).
12. Using the Tie-Rod End Remover, separate the outer tie-rod ends from the wheel knuckles.
13. Remove the lower control arm-to-knuckle nuts and bolts and separate the lower control arms from the knuckles. Discard the nuts and bolts. To install, tighten to 55 Nm (41 lb-ft).
14. Remove the 2 roll restrictor heat shield nuts and the roll restrictor heat shield. To install, tighten to 11 Nm (97 lb-in).
15. Remove the roll restrictor-to-front subframe bolt. Clean the bolt using a wire brush and apply new threadlock to the threads. To install, tighten to 115 Nm (85 lb-ft).
16. Position the Powertrain Lift under the front subframe.
17. Remove and discard the 2 crossbrace-to-front subframe support bracket bolts and remove the crossbrace. To install, tighten the new bolts to 90 Nm (66 lb-ft).
18. Remove the 2 front subframe support bracket bolts, the 2 rearward subframe mounting nuts and the front subframe support brackets. Discard the nuts and bolts. To install, tighten the new nuts to 133 Nm (98 lb-ft). To install, tighten the new bolts to 90 Nm (66 lb-ft).
19. Remove and discard the 2 forward subframe mounting nuts. To install, tighten the new nuts to 133 Nm (98 lb-ft).
20. Remove and discard the 2 middle subframe mounting nuts. To install, tighten the new nuts to 133 Nm (98 lb-ft).
21. Using the Powertrain Lift, lower the front subframe approximately 101 mm (3.976 in).
22. Remove and discard the pressure line-to-steering gear banjo bolt and 2 seals. On installation, replace the 2 seals. To install, tighten the new banjo bolt to 48 Nm (35 lb-ft).
23. Remove the 2 steering gear heat shield bolts and the steering gear heat shield. To install, tighten to 6 Nm (53 lb-in).
24. Remove the 3 steering line bracket-to-steering gear bracket bolts. To install, tighten to 9 Nm (80 lb-in).
25. Remove the 2 steering line bracket-to-subframe bolts. To install, tighten to 9 Nm (80 lb-in).
26. Release the clamp and disconnect the return hose from the steering gear.
27. Remove the front subframe.

Installation

1. To install, reverse the removal procedure.
2. Fill the power steering system. For additional Information, refer to «STEERING SYSTEM»(ref-494570) .

Subframe - Rear

SPECIAL TOOLS CHART Powertrain Lift 300-OTC1585AE or equivalent

Scheme 32

Scheme 33

Note. Suspension and subframe fasteners are critical parts because they affect performance of vital parts and systems and their failure may result in major service expense. A new part with the same part number must be installed if installation becomes necessary. Do not use a replacement part of lesser quality or substitute design. Torque values must be used as specified during reassembly to make sure of correct retention of these parts.

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

1. Remove the rear wheels. For additional information, refer to «WHEELS AND TIRES»(ref-494563) .
2. If equipped, remove the bolts from the driveshaft-to-rear drive unit flange. To install, tighten to 70 Nm (52 lb-ft).
3. With a wax pencil, mark the relationship of the rear subframe to the underbody at the mounting locations.
4. Remove the muffler and tailpipe assembly.
5. Disconnect the LH and RH wheel speed sensor connectors.
6. Remove the connector from the front of the subframe and position aside.
7. Remove the 4 bolts (2 each side) from the rear hub spindle-to-brake caliper. To install, tighten to 70 Nm (52 lb-ft).
8. Remove the 2 bolts (1 each side) from the brake hose bracket.
9. Position the brake calipers aside using mechanic's wire. It is not necessary to disconnect the hydraulic brake lines.
10. Remove the 2 nuts (1 each side) from the parking brake cable bracket and upper stabilizer shaft. Discard the nuts. To install, tighten to 35 Nm (26 lb-ft).
11. Remove the 4 bolts (2 each side) from the parking brake cable-to-backing plate. To install, tighten to 23 Nm (17 lb-ft).
12. Remove the rear shock-to-trailing link lower nuts and flag bolts. Discard the nuts and flag bolts. To install, tighten to 80 Nm (59 lb-ft).
13. Position the lifting table under the rear subframe.
14. Remove the 4 front (2 each side) bushing brace-to-body bolts. Discard the bolts. To install, tighten to 25 Nm (18 lb-ft).
15. Remove the 2 front (1 each side) mounting bolts from the rear subframe. Discard the bolts. To install, tighten to 150 Nm (111 lb-ft).
16. Remove the 10 bolts (5 each side) from the trailing links-to-vehicle body. Discard the bolts. To install, tighten to 47 Nm (35 lb-ft).
17. Remove the 2 rear mounting bolts. Discard the bolts. To install, tighten to 150 Nm (111 lb-ft).
18. Remove the rear subframe.
19. Transfer the components as necessary.
20. To install, reverse the removal procedure.

Note. There are 2 Rear Drive Unit (RDU) bushings in the rear subframe, this procedure shows how to remove one bushing. The procedure for the remaining RDU bushing is identical.

Scheme 47

1. Remove the RDU. For additional information, refer to «REAR DRIVE AXLE/DIFFERENTIAL»(ref-494588) .
2. NOTE: Make sure the Rear Drive Unit (RDU) Bushing Remover/Installer 204-617/2 is positioned with the larger opening toward the bushing to act as the receiver cup. NOTE: Make sure the arrow on the special tool is pointed toward the rear subframe when removing the bushing.

Note. There are 2 RDU bushings in the subframe, this procedure shows how to install one bushing. The procedure for the remaining RDU bushing is identical.

Scheme 48

1. Install the RDU bushing into the Rear Drive Unit (RDU) Bushing (65 mm) Remover/Installer.
2. Install the Rear Drive Unit (RDU) Bushing (65 mm) Remover/Installer onto the RDU bushing.
3. Inspect the rear subframe to find the revision part number.
4. Install the RDU bushing into the subframe.
5. Install the RDU. For additional information, refer to «REAR DRIVE AXLE/DIFFERENTIAL»(ref-494588) .
