TORQUE SPECIFICATIONS
| Description | Nm |
|---|
| Floor console center bolts | 6 |
| Floor console front side bolts | 6 |
| Floor console rear bolts | 6 |
| Floor console-to-instrument panel bolts | 6 |
| Front of dash bolt | 20 |
| Instrument panel-to-steering column bracket bolts | 22 |
| LH instrument panel bolts | 20 |
| LH instrument panel-to-body bolt | 7 |
| LH instrument panel-to-floor bolts | 22 |
| RH instrument panel bolt | 22 |
| RH instrument panel-to-body bolt | 7 |
| RH instrument panel-to-floor bolt | 22 |
| Steering column pinch bolt | 23 |
| Torx head bolt | 30 |
Scheme 61
Scheme 61: Instrument Panel - Exploded View
| Item | Part Number | Description |
|---|
| 1 | W505002 | Steering column cover screw (2 required) |
| 2 | 04459 | Steering column opening cover |
| 3 | W707628 | Instrument panel cluster finish panel screw (2 required) |
| 4 | 044D70 | Instrument panel cluster finish panel |
| 5 | 04608 | Instrument panel lower center finish panel |
| 6 | 04302 | Instrument panel upper center finish panel |
| 7 | 06024 | Glove compartment |
| 8 | 061A58 | Glove compartment dampener |
| 9 | 04480 | RH instrument panel end trim panel |
| 10 | 04481 | LH instrument panel end trim panel |
Scheme 62
| Item | Part Number | Description |
|---|
| 11 | W712386 | LH instrument panel bolt (2 required) |
| 12 | W712387 | Torx head bolt |
| 13 | W711648 | Instrument panel-to-steering column bracket bolt (2 required) |
| 14 | W706246 | RH instrument panel bolt |
| 15 | W710309 | Instrument panel-to-front of dash bolt |
| 16 | W712403 | LH instrument panel-to-body bolt |
| 17 | 3RA27 | Steering column pinch bolt |
| 18 | W706246 | Instrument panel-to-floor bolt (3 required) |
| 19 | W706246 | RH instrument panel-to-body bolt |
| 20 | 14401 | LH instrument panel electrical connectors |
| 21 | 14401 | Restraints control module (RCM) electrical connector |
| 22 | | Antenna lead-in |
| 23 | 14401 | RH instrument panel electrical connector |
| 24 | 04320 | Instrument panel |
Scheme 63
| Item | Part Number | Description |
|---|
| 1 | W505002 | Steering column cover screw (2 required) |
| 2 | 04459 | Steering column opening cover |
| 3 | W707628 | Instrument panel cluster finish panel screw (2 required) |
| 4 | 044D70 | Instrument panel cluster finish panel |
| 5 | N811283 | Instrument panel storage bin screw (2 required) |
| 6 | 047A04 | Instrument panel storage bin |
| 7 | 04302 | Instrument panel lower center finish panel |
| 8 | 042A82 | Instrument panel upper center finish panel |
| 9 | 06024 | Glove compartment |
| 10 | 061A58 | Glove compartment dampener |
| 11 | 04480 | RH instrument panel end trim panel |
| 12 | 04481 | LH instrument panel end trim panel |
Scheme 64
| Item | Part Number | Description |
|---|
| 13 | W712386 | LH instrument panel bolt (2 required) |
| 14 | W712387 | Torx head bolt |
| 15 | W711648 | Instrument panel-to-steering column bracket bolt (2 required) |
| 16 | W706246 | RH instrument panel bolt |
| 17 | W712403 | Instrument panel-to-front of dash bolt |
| 18 | W703845 | LH instrument panel-to-body bolt |
| 19 | 3RA27 | Steering column pinch bolt |
| 20 | W706246 | Instrument panel-to-floor bolt (3 required) |
| 21 | W703845 | RH instrument panel-to-body bolt |
| 22 | 14401 | LH instrument panel electrical connectors |
| 23 | 14401 | Restraints control module (RCM) electrical connector |
| 24 | | Antenna lead-in |
| 25 | 14401 | RH instrument panel electrical connector |
| 26 | 04320 | Instrument panel |
- For additional information, refer to the appropriate procedure.
