Subframe and Mounting Systems

Front Subframe - The front subframe is bolted to the body and is used to

1. aid in structural support.
2. provide mounting surfaces for the front suspension control arms.
3. provide the mounting surface for the steering gear.
4. provide the mounting surface for the sway bar.

Rear Subframe - The rear subframe is bolted to the body and is used to

1. aid in structural support.
2. provide mounting surfaces for the rear suspension control arms.
3. provide a mounting point for the rear differential, if equipped.
4. provide a mounting surface for the sway bar.

Underbody misalignment can affect front and rear wheel alignment, the operation of the suspension parts and drivetrain operation. Window glass cracks, door and window opening concerns and air or water leaks at the doors are often caused by incorrectly tightened bolts and body misalignment. For body misalignment and checking, refer to BODY REPAIRS article. Before any welding is carried out on the vehicle, refer to BODY REPAIRS article.

Subframe - Front

Special Tools Illustration Tool Name Tool Number Powertrain Lift Table 014-00765

Scheme 1

Scheme 2

1. With a wax pencil, mark the relationship of the front subframe to the underbody at the mounting locations.
2. Remove the RH splash shield. For additional information, refer to «FRONT END BODY PANELS»(ref-292537) article.
3. Remove the 3 pushpin fasteners, the 7 screws and the front splash shield.
4. Remove the 3 RH subframe-to-lower bumper nuts. To install, tighten to 9 N.m (80 lb-in).
5. Remove the 3 LH subframe-to-lower bumper nuts and separate the lower bumper from the subframe. To install, tighten to 9 N.m (80 lb-in).
6. Remove the 3 power steering tube bracket bolts from the RH side of the subframe and position the power steering tube aside. To install, tighten to 9 N.m (80 lb-in).
7. Remove the 2 stabilizer bar link-to-control arm nuts (1 each side) and separate the stabilizer bar links from the lower control arms. Discard the nuts. To install, tighten to 90 N.m (66 lb-ft).
8. Remove the lower control arm-to-knuckle pinch bolts and separate the lower control arms from the knuckles. Discard the bolts. To install, tighten to 55 N.m (41 lb-ft).
9. Loosen the Y-pipe clamp and disconnect the 2 exhaust hangers. To install, tighten to 40 N.m (30 lb-ft).
10. Remove the 4 nuts and the Y-pipe assembly. To install, tighten to 40 N.m (30 lb-ft).
11. Remove the 4 bolts and position the steering rack aside using a suitable length of mechanic's wire. Discard the bolts. To install, tighten the steering gear bolts in the sequence shown. To install, tighten to 103 N.m (76 lb-ft).
12. Remove the 4 bolts and position the stabilizer bar aside using a suitable length of mechanic's wire. Discard the bolts. To install, tighten to 63 N.m (46 lb-ft).
13. Remove the nuts and the roll restrictor heat shield. To install, tighten to 11 N.m (8 lb-ft).
14. Remove the 3 bolts from the roll restrictor bracket. To install, tighten to 90 N.m (66 lb-ft).
15. Position the lift table under the subframe.
16. Remove the 2 nuts, 4 bolts and the subframe support brackets. Discard the nuts and bolts. To install, tighten the nuts to 133 N.m (98 lb-ft). To install, tighten the bolts to 90 N.m (66 lb-ft).
17. Remove the 2 front subframe nuts. Discard the nuts. To install, tighten to 133 N.m (98 lb-ft).
18. Remove the 2 middle subframe nuts and remove the subframe. Discard the nuts. To install, tighten to 133 N.m (98 lb-ft).
19. Transfer the components as necessary.
20. To install, reverse the removal procedure.

Subframe - Rear

Special Tools Illustration Tool Name Tool Number Powertrain Lift Table 014-00765

Scheme 3

Scheme 4

1. Remove the rear wheels. For additional information, refer to «WHEELS & TIRES»(ref-292521) article.
2. If equipped, remove the bolts from the drive shaft-to-rear drive unit flange. To install, tighten to 70 N.m (52 lb-ft).
3. With a wax pencil, mark the relationship of the rear subframe to the underbody at the mounting locations.
4. Remove the muffler and tailpipe assembly.
5. Disconnect the LH and RH wheel speed sensor connectors.
6. Remove the connector from the front of the subframe and position aside.
7. Remove the 4 bolts (2 each side) from the rear hub spindle-to-brake caliper. To install, tighten to 70 N.m (52 lb-ft).
8. Remove the 2 bolts (1 each side) from the brake hose bracket.
9. Position the brake calipers aside using mechanic's wire. It is not necessary to disconnect the hydraulic brake lines.
10. Remove the 2 nuts (1 each side) from the parking brake cable bracket and upper stabilizer shaft. Discard the nuts. To install, tighten to 35 N.m (26 lb-ft).
11. Remove the 4 bolts (2 each side) from the parking brake cable-to-backing plate. To install, tighten to 23 N.m (17 lb-ft).
12. Remove the rear shock-to-trailing link lower nuts and flag bolts. Discard the nuts and flag bolts. To install, tighten to 80 N.m (59 lb-ft).
13. Position the lifting table under the rear subframe.
14. Remove the 4 front (2 each side) bushing brace-to-body bolts. Discard the bolts. To install, tighten to 25 N.m (18 lb-ft).
15. Remove the 2 front (1 each side) mounting nuts from the rear subframe. Discard the nuts. To install, tighten to 90 N.m (66 lb-ft).
16. Remove the 10 bolts (5 each side) from the trailing links-to-vehicle body. Discard the bolts. To install, tighten to 47 N.m (35 lb-ft).
17. Remove the 2 rear mounting nuts. Discard the nuts. To install, tighten to 90 N.m (66 lb-ft).
18. Remove the rear subframe.
19. Transfer the components as necessary.
20. To install, reverse the removal procedure.

Subframe Bushings - Differential, Rear

Special Tools Illustration Tool Name Tool Number Remover/Installer, Rear Drive Unit (RDU) Bushing (70 mm) 204-616 Remove/Installer, Rear Drive Unit (RDU) Bushing (65 mm) 204-617 Remover/Installer, Rear Drive Unit (RDU) Bushing (60 mm) 204-618

Scheme 5
