Starting System - Starter - Diesel: Specifications — Ford Econoline E350 (1997-1998)

Starting System - Starter - Diesel: Specifications Ford Econoline E350

Starter 1 illustration

STARTER SPECIFICATIONS

Application			Specification
Brush Length
3.0" (78 mm) Motor			.66" (16.8 mm)
3.4" (85 mm) Motor			.71" (18 mm)
Brush Spring Tension
3.0" (78 mm) Motor			64 ozs. (2.3 kg)
3.4" (85 mm) Motor			122 ozs. (3.5 kg)
Commutator Runout			(1) .005" (.12 mm)
Pinion Depth Gap			.004-.079" (0.10-2.00 mm)
Starter Load Test
Normal Load Current Draw
3.0" (78 mm) Motor			130-220 Amps
3.4" (85 mm) Motor			230-630 Amps
Maximum Load Current Draw
3.0" (78 mm) Motor			800 Amps
3.4" (85 mm) Motor			2400 Amps
Starter No-Load Test
Maximum Current Draw
3.0" (78 mm) Motor			60-80 Amps
3.4" (85 mm) Motor			170 Amps
(1) Replace armature if runout exceeds specification.

(1)	Replace armature if runout exceeds specification.
