INTERIOR FUSE PANEL IDENTIFICATION (E-SERIES) - 1994-96

The fuse panel for E-150/250/350 is located on a mounting bracket under the instrument panel, left of the steering column.

Scheme 1

Scheme 1: INTERIOR FUSE PANEL IDENTIFICATION (E-SERIES) - 1994-96

Interior Fuse & Circuit Breaker Identification

  1. 1 - 15 Amp (1994-95) - Stoplights, Hazard Flasher, Speed Control 15 Amp (1996) - Brake Pressure Switch, DLC, PSOM, Stoplights, Hazard Flasher, Speed Control
  2. 2 - 8.25 Amp (Circuit Breaker) (1994-95) - Wiper/Washer 30 Amp (1996) - Wiper Control Module, Windshield Wiper Motor
  3. 3 - Not Used
  4. 4 - 20 Amp - Turn, Instrument Illumination, License & Running Lights, Flash-To-Pass, Anti-Theft Module, Warning Chime, Trailer Running/Backup Light Relay
  5. 5 - 15 Amp - Air Bag Module, DRL Module, Trailer Battery Charge Relay, Aux Battery Relay, Starting System, Turn Signal, Back-Up Lights, Transmission Control Switch
  6. 6 - 20 Amp - Speed Control, Illuminated Entry, Anti-Theft Module Customer Convenience Plug (located Below Fuse) Hot In RUN or ACCY
  7. 7 - 10 Amp - Ignition Coil, Anti-Theft Module, Transmission Range Sensor, Park/Neutral Position Switch, PCM
  8. 8 - 15 Amp - Courtesy Light Switch, Illuminated Entry, Power Mirrors, Power Door Lock, Anti-Theft Indicator, Dome, Map & Rear Cargo Lights, Radio Memory, PSOM, Remote Convenience Module
  9. 9 - 15 Amp - A/C-Heater Blower Motor Switch
  10. 10 - 20/30 Amp (1994-95) - Cigarette Lighter, Rear Power Outlet 25 Amp (1996) - Cigarette Lighter, Power Amplifier, Rear Power Outlet
  11. 11 - 15 Amp - Radio, Clock, Headlight Switch
  12. 12 - 20 Amp (Circuit Breaker) - Power Door Locks, Anti-Theft Module, Remote Convenience Module, Memory Lock Module
  13. 13 - 5 Amp - Instrument Panel Illumination
  14. 14 - 20 Amp (Circuit Breaker) - Power Windows
  15. 15 - 20 Amp - Air Bag Module
  16. 16 - 30 Amp - Power Lumbar, Modified Vehicle Tap
  17. 17 - 20 Amp - Anti-Lock Brake Module, PSOM
  18. 18 - 15 Amp - Instrument Warning Lights, Warning Buzzer, Rear Anti-Lock Warning

UNDERHOOD FUSE PANEL IDENTIFICATION - 1994-96

The underhood fuse panel (power distribution box) is located in the engine compartment near the left-hand fender apron.

WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Fuse & Relay Identification

  1. A - 60 Amp (1994-95) - Aux Heater-A/C, Remote Convenience Module 50 Amp (1996) - Aux Heater-A/C
  2. B - 50 Amp - Modified Vehicle Power
  3. C - 30 Amp - EEC/TCM
  4. D - 20 Amp - Electric Brake
  5. E - 50 Amp - Power Seats, Driver Power Lumbar
  6. F - 60 Amp - Blower Motor, Cigarette Lighter
  7. G - 60 Amp - Ignition Switch
  8. H - 30 Amp - Fuel Pump
  9. J - 40 Amp - Trailer Tow
  10. K - 30 Amp - Trailer Tow, Back-up Lights
  11. L - Diode - Electronic Engine Control
  12. M - 10 Amp - Trailer R/H Turn/Stop Light
  13. N - 10 Amp - Trailer L/H Turn/Stop Light
  14. P - 10 Amp - Class I Trailer Running Lights, Class II Trailer Running Lights Relay
  15. R - 15 Amp - DRL Module, Horn Relay, Underhood Light
  16. S - 60 Amp (1994-95) - Headlight Switch, I/P
  17. 60 Amp (1996) - Interior Fuse Panel Power Feed
  18. T - 60 Amp - Trailer Tow, Aux Battery Relay
  19. RA - Relay - Electronic Engine Control
  20. RB - Relay - Fuel Pump
  21. RC - Relay - Horn
  22. RD - Relay (1994-95) - Blower Motor
  23. RD - 60 Amp & 30 Amp (1996) - ABS Module, ECC Relay Coil

INTERIOR FUSE PANEL IDENTIFICATION (E-SERIES) - 1997-99

The fuse panel for E-150/250/350 is located on a mounting bracket under the instrument panel, left of the steering column.

Scheme 4

Scheme 4: INTERIOR FUSE PANEL IDENTIFICATION (E-SERIES) - 1997-99

Interior Fuse & Circuit Breaker Identification

  1. 1 - 20 Amp - RABS/4WABS Module
  2. 2 - 15 Amp - Brake Warinin Diode/Resistor, Instrument Cluster, Warning Chime, 4WABS Relay, Warning Indicators
  3. 3 - 15 Amp - Main Light Switch, RKE Module, Radio
  4. 4 - 15 Amp - Power Locks w/ RKE, Illuminated Entry, Warning Chime, Modified Vehcicle, Power Mirrors, Main Light Switch, Courtesy Lamps
  5. 5 - 20 Amp - RKE Module, Power Lok Switches, Memory Lock
  6. 6 - 10 Amp - Shift Interlock, Speed Control, DRL Module
  7. 7 - 10 Amp - Multi-Function Switch
  8. 8 - 30 Amp - Radio Capacitors, Ignition Coil, PCM Diode, PCM Power Relay, Fuel Heater, Glow Plug Relay (Diesel)
  9. 9 - 30 Amp - Wiper Control Module, Windshield Wiper Motor
  10. 10 - 20 Amp - Main Light Switch, (External Lamps) Multi-Function Switch (Flash to Pass)
  11. 11 - 15 Amp - Brake Pressure Switch, Multi-Function Switch (Hazards), RABS, Brake Pedal Position Switch
  12. 12 - 15 Amp - Transmission Range Sensor, Auxiliary Battery Relay
  13. 13 - 15 Amp - Blend Door Actuator, Function Selector Switch
  14. 14 - 5 Amp - Instrument Cluster (Air Bag & Charge Indicator)
  15. 15 - 5 Amp - Trailer Battery Charge Relay
  16. 16 - 30 Amp - Power Seats
  17. 17 - Not Used
  18. 18 - Not Used
  19. 19 - 10 Amp - Airbag Diagnostic Monitor
  20. 20 - 5 Amp - Overdrive Cancel Switch
  21. 21 - 30 Amp - Power Windows
  22. 22 - 15 Amp - Memory Power Radio
  23. 23 - 20 Amp - Cigar Lighter, Data Link Connector (DLC)
  24. 24 - 5 Amp - Illuminated Entry Module
  25. 25 - 10 Amp - Left Headlamp (Low Beam)
  26. 26 - Not Used
  27. 27 - 5 Amp - Radio
  28. 28 - 25 Amp - Power Plug
  29. 29 - Not Used
  30. 30 - 15 Amp - Headlamps (High Beam Indicator), DRL
  31. 31 - 10 Amp - Right Headlamp (Low Beam), DRL
  32. 32 - Not Used
  33. 33 - Not Used
  34. 34 - 10 Amp - Transmission Range Sensor
  35. 35 - Not Used
  36. 36 - 5 Amp - (Cluster, A/C, Illumination, Radio), Steering Column Assembly
  37. 37 - Not Used
  38. 38 - 10 Amp - Air Bag Diagnostic Monitor
  39. 39 - Not Used
  40. 40 - 30 Amp - Modified Vehicle
  41. 41 - 30 Amp - Modified Vehicle
  42. 42 - Not Used
  43. 43 - 20 Amp (Circuit Breaker) - Power Windows
  44. 44 - Not Used

UNDERHOOD FUSE PANEL IDENTIFICATION - 1997-99

The underhood fuse panel (power distribution box) is located in the engine compartment near the left-hand fender apron.

WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

Scheme 5

Scheme 5

Fuse & Relay Identification

  1. 1 - Not Used
  2. 2 - Not Used
  3. 3 - Not Used
  4. 4 - 5 Amp (1997) - PCM Keep Alive Memory 10 Amp (1998) - PCM Keep Alive Memory, Instrument Cluster
  5. 5 - 10 Amp - Right Trailer Turn Signal
  6. 6 - 10 Amp - Left Trailer Turn Signal
  7. 7 - Not Used
  8. 8 - 60 Amp - I/P Fuses 5,11,23,38,4,10,16,28
  9. 9 - 30 Amp - PCM Power Relay
  10. 10 - 60 Amp - Auxiliary Battery Relay, Engine Compartment Fuses 14, 22
  11. 11 - Not Used
  12. 12 - 60 Amp - Engine Compartment Fuses 26,27
  13. 13 - 50 Amp - Blower Motor Relay (Blower Motor)
  14. 14 - 30 Amp - Trailer Running Lamps, Trailer Back-Up Lamps
  15. 15 - 40 Amp - Main Light Switch
  16. 16 - 50 Amp - Auxiliary A/C, RKE Module
  17. 17 - 30 Amp - Fuel Pump Relay, IDM (Diesel)
  18. 18 - 60 Amp - I/P Fuses 40 & 41
  19. 19 - 60 Amp - 4WABS Module
  20. 20 - 20 Amp - Electric Brake Controller
  21. 21 - 50 Amp - Modified Vehicle Power
  22. 22 - 40 Amp - Trailer Battery Charge Relay, Modified Vehicle
  23. 23 - 60 Amp - Ignition Switch
  24. 24 - Not Used
  25. 25 - Not Used
  26. 26 - 10 Amp - Generator/Voltage Regulator (Diesel Only)
  27. 27 - 15 Amp - Horn, DRL Module
  28. 28 - Diode - PCM Diode
  29. 29 - Not Used
  30. A - Not Used
  31. B - Not Used
  32. C - Relay - Trailer Backup Lamps Relay
  33. D - Relay - Trailer Running Lamps Relay
  34. E - Relay - Trailer Battery Charge Relay
  35. F - Relay - Not Used
  36. G - Relay - PCM Relay
  37. H - Relay - Blower Motor Relay
  38. J - Relay - Horn Relay
  39. K - Relay - Fuel Pump Relay, IDM Relay (Diesel)
