Engine Controls - Pinpoint Tests - 6.0L Diesel: Overview Ford Econoline E350 Super Duty

Testing & Diagnostics 3 illustrations ~1029 words

DTC Description

  1. P0562 = System Voltage Low
  2. P0563 = System Voltage High

Scheme 173

Scheme 173
  1. P0830 = Clutch Switch A Circuit
  2. P0833 = Clutch Switch B Circuit

DTC Descriptions

  1. P0335 = Crankshaft Position Sensor Circuit A
  2. P0336 = Crankshaft Position Sensor Circuit A Range/Performance
  3. P2617 = Crankshaft Position Out Fault
  1. P0236 = Turbo Boost Sensor A Circuit Performance
  2. P0237 = Turbo Boost Sensor A Circuit Low Input
  3. P0238 = Turbo Boost Sensor A Circuit High Input
VoltsKPaPis
0.02202.9
0.5507.25
0.9276.611.1
3.8255.937.1
4.4929943.4
530043.5
NOTE: +/- 0.3 volt from expected voltage reading is allowed.
NOTE
+/- 0.3 volt from expected voltage reading is allowed.

EP SENSOR SPECIFICATIONS

  1. P0113 = IAT Sensor Circuit High Input
  2. P0112 = IAT Sensor Circuit Low Input
  1. P0096 = IAT2 Sensor 2 Circuit Range/Performance
  2. P0097 = IAT2 Sensor 2 Circuit Low Input
  3. P0098 = IAT2 Sensor 2 Circuit High Input
  1. P0107 = BARO Sensor Low Input
  2. P0108 = BARO Sensor High Input

Note. Compare the BARO sensor value with the local barometric values.

Scheme 174

Scheme 174
  1. P1536 = Parking Brake Switch Circuit
  1. P0101 = Mass or Volume Air Flow Circuit Range/Performance
  2. P0103 = Mass or Volume Air Flow Circuit High Input
  3. P1102 = Mass Air Flow Sensor In Range But Lower Than Expected
  1. P0117 = ECT Sensor Circuit Low Input
  2. P0118 = ECT Sensor Circuit High Input
  1. Circuit Faults: P0196 = EOT Sensor Circuit Range/Performance P0197 = EOT Sensor Circuit Low Input P0198 = EOT Sensor Circuit High Input P1184 = EOT Sensor Out Of Self-Test Range P0298 = Engine Oil Over Temperature Condition
  1. P0230 = Fuel Pump Primary Circuit
  2. P0231 = Fuel Pump Secondary Circuit Low
  3. P0232 = Fuel Pump Secondary Circuit High
CAUTIONThe PCM harness connectors must be properly seated and the connector latch properly attached to eliminate possible driveability concerns or a no-start condition. Installing PCM connectors on an angle may cause an improper connection, misdiagnosis, and damaged components. Install the connector until the lever pivots and seats itself. Apply light pressure to get the connector into position on the PCM and then fully seat the connector.

Note. Visually inspect the harness connectors for corrosion, damage, proper mating, and correct pin tension.

  1. P2269 = Water In Fuel Condition
  1. P2285 = ICP Circuit Out Of Range Low
  2. P2286 = ICP Circuit Out Of Range High
  3. P2287 = ICP Sensor Circuit Intermittent
  1. P2623 = Injector Control Pressure Regulator Circuit
  1. P0611 = FICM Performance
  2. P1378 = FICM Circuit Low Voltage
  3. P1379 = FICM Circuit High Voltage
  1. P0340 = CMP Sensor Circuit Malfunction
  2. P0341 = CMP Sensor Circuit Performance
  3. P2614 = Camshaft Position Out
  1. P0401 = EGR Flow Insufficient Detected
  2. P0402 = EGR Flow Excessive Detected
  3. P0403 = EGR Control Circuits
  4. P0404 = EGR Control Circuit Range/Performance
  5. P0405 = EGR Sensor A Circuit Low
  6. P0406 = EGR Sensor A Circuit High
  7. P1335 = EGR Position Sensor Minimum Stop Performance
  1. P0470 = Exhaust Pressure Sensor
  2. P0471 = Exhaust Pressure Sensor Range/Performance
  3. P0472 = Exhaust Pressure Sensor Low Input
  4. P0473 = Exhaust Pressure Sensor High Input
KPaEP (volts)
43.80.05
70.50.45
101.50.90
325.54.14
365.44.75
  1. P0565 = Speed Control ON Signal
  2. P0566 = Speed Control OFF Signal
  3. P0567 = Speed Control RESUME Signal
  4. P0568 = Speed Control SET Signal
  5. P0569 = Speed Control COAST Signal
  1. P0606 = ECM/PCM Processor
  2. P1633 = Keep Alive Power Voltage Too Low

Description

The PCM reset occurs when the PCM momentarily reboots or is turned off and on while the engine is operating. If the condition occurs a single time, the engine momentarily stumbles and the PCM goes through a normal key on cycle, including turning the glow plug lamp and glow plugs on, and attempts to validate the accelerator pedal position. If the pedal is not at the idle position when this fault occurs, pedal authority is not allowed by the PCM until the accelerator pedal is released and the engine returns to idle.

CAUTIONThe PCM harness connectors must be properly seated and the connector latch properly attached to eliminate possible driveability concerns or a no start condition. Installing the PCM connectors on an angle may cause an improper connection, misdiagnosis, and damaged components. Install the connector until the lever pivots and seats itself. Apply light pressure to get the connector into position on the PCM and then fully seat the connector.

Note. Visually inspect the harness connectors for corrosion, damage, proper mating, and correct pin tension.

The glow plug system is composed of a solid state glow plug control module (GPCM) and the glow plugs. The GPCM provides direct battery voltage to the glow plugs. The GPCM monitors the individual glow plug operation. Faults detected by the GPCM are transmitted to the PCM using a serial communication signal on a diagnostic line.

The powertrain control module (PCM) enables and controls the GPCM. The glow plug ON time is a function of oil temperature, barometric pressure, and battery voltage. The ON time normally varies between 1 to 120 seconds and is limited by the GPCM to 180 seconds regardless of PCM commands.

Note. Wait-to-Start indicator ON time is independent from GPCM ON time.

  1. P0670 = Glow Plug Module Control Circuit
  2. P0671 - P0678 = Cylinder 1 - 8 Glow Plug Circuit
  3. P0683 = Glow Plug Control Module to PCM Communication Circuit
  1. P2104 = Throttle Actuator Control System Forced Idle
  2. P2122 = APP Sensor D Low Input
  3. P2123 = APP Sensor D High Input
  4. P2127 = APP Sensor E Low Input
  5. P2128 = APP Sensor E High Input
  6. P2132 = APP Sensor F Low Input
  7. P2133 = APP Sensor F High Input
  8. P2138 = APP Sensor D/E Voltage Correlation
  9. P2139 = APP Sensor D/F Voltage Correlation
  10. P2140 = APP Sensor E/F Voltage Correlation
  1. P0480 = Fan 1 Control Circuit
  2. P0528 = Fan Speed Sensor Circuit No Signal

This pinpoint test is intended to diagnose the following

  1. visctronic drive fan
  2. fan speed sensor
  3. harness circuits
  4. powertrain control module (PCM)

Scheme 175

Scheme 175: Pinpoint Test Schematics and Connectors
  1. P1703 = Brake Switch Out of Self-Test Range
  1. P0046 = Turbo/Supercharger Boost Solenoid Circuit Range/Performance Fault
  1. P1502 - Invalid Test - Auxiliary Powertrain Control Functioning
  1. P2284 = Injector Control Pressure Sensor Circuit Range/Performance
  2. P2288 = Injector Control Pressure Too High
  1. P2289 = Injection Control Pressure Too High - KOEO
  1. P2291 = Injection Control Pressure Too Low - Engine Cranking
  1. P0300 = Random Misfire Detected
  1. U0105 = Loss of Communication With The FICM
  1. P0148 = Fuel Error/Engine Speed Higher Than Expected.
  2. P2552 = FICMM Circuit - Throttle/Fuel Inhibit Circuit.
  1. P0069 = BARO/MAP Correlation
  1. P0645 = A/C Clutch Relay Control Circuit
  1. P2199 = Intake Air Temperature 1/2 Correlation
  1. P0703 = Brake Switch B Input Circuit
  1. P2457 = Exhaust Gas Recirculation (EGR) Cooler System Performance
  1. P0500 = Vehicle Speed Sensor A
  2. P1501 = Vehicle Speed Sensor Out Of Self-Test Range
  1. P0299 = Turbo/Super Charger Underboost
  2. P0478 = Exhaust Pressure Control Valve High Input
  3. P2262 = Turbo/Super Charger Boost Pressure Not Detected
  4. P2263 = Turbo/Super Charger System Boost Performance
  1. P0460 = Fuel Level Sensor A Circuit
  2. P0461 = Fuel Level Sensor A Circuit Low Input
  3. P0462 = Fuel Level Sensor A Circuit High Input
  4. P115A = Low Fuel Level - Forced Limited Power
  5. P2067 = Fuel Level Sensor B Circuit Low Input
  6. P2068 = Fuel Level Sensor B Circuit High Input
