Multifunction Electronic Modules: Diagnosis Ford Econoline E350 Super Duty

Communication Devices 4 illustrations ~450 words

Diagnostic Trouble Code Chart

DTCDescriptionSourceAction
B1202Fuel Sender Circuit OpenInstrument ClusterREFER to INSTRUMENT CLUSTER .
B1204Fuel Sender Circuit Short to GroundInstrument ClusterREFER to INSTRUMENT CLUSTER .
B1205EIC Switch-1 Assembly Circuit FailureInstrument ClusterREFER to INSTRUMENT CLUSTER .
B1231Longitudinal Acceleration Threshold ExceededRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1309Power Door Lock Circuit Short to GroundVehicle Security ModuleREFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1317Battery Voltage HighInstrument ClusterREFER to CHARGING SYSTEM - GENERAL INFORMATION .
B1317Battery Voltage HighRCMREFER to CHARGING SYSTEM - GENERAL INFORMATION .
B1318Battery Voltage LowInstrument ClusterREFER to CHARGING SYSTEM - GENERAL INFORMATION .
B1318Battery Voltage LowRCMREFER to CHARGING SYSTEM - GENERAL INFORMATION .
B1319Driver Door Ajar Circuit FailureInstrument ClusterREFER to INTERIOR LIGHTING .
B1322Driver Door Ajar Circuit Short to GroundVehicle Security ModuleREFER to INTERIOR LIGHTING .
B1327Passenger Door Ajar Circuit FailureInstrument ClusterREFER to INTERIOR LIGHTING .
B1330Passenger Door Ajar Circuit Short to GroundVehicle Security ModuleREFER to INTERIOR LIGHTING .
B1334Decklid Ajar Rear Door Circuit Short to GroundVehicle Security ModuleREFER to INTERIOR LIGHTING .
B1338Door Ajar RR Circuit Short to GroundVehicle Security ModuleREFER to INTERIOR LIGHTING .
B1341Power Door Unlock Circuit Short to GroundVehicle Security ModuleREFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1342ECU is DefectiveABS ModuleCLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new ABS module. REFER to ANTI-LOCK CONTROL . CLEAR the DTCs. REPEAT the self-test.
B1342ECU is DefectiveInstrument ClusterCLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new instrument cluster. REFER to INSTRUMENT CLUSTER . CLEAR the DTCs. REPEAT the self-test.
B1342ECU is DefectiveRCMCLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new RCM. REFER to SUPPLEMENTAL RESTRAINT SYSTEM . CLEAR the DTCs. REPEAT the self-test.
B1342ECU is DefectiveVehicle Security ModuleCLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new vehicle security module. REFER to VEHICLE SECURITY MODULE in this section. CLEAR the DTCs. REPEAT the self-test.
B1352Ignition Key-In Circuit FailureInstrument ClusterREFER to WARNING DEVICES .
B1360Ignition Run/Ace Circuit OpenInstrument ClusterREFER to INSTRUMENT CLUSTER .
B1463Seatbelt Switch Circuit OpenInstrument ClusterREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1485Brake Pedal Input Short to BatteryVehicle Security ModuleREFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1522Hood Switch Circuit Short to GroundVehicle Security ModuleREFER to INTERIOR LIGHTING .
B1526Keyless Entry Circuit Short to GroundVehicle Security ModuleREFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1562Door Lock Cylinder Circuit Short to GroundVehicle Security ModuleREFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1607Illuminated Entry Input Circuit FailureInstrument ClusterREFER to INTERIOR LIGHTING .
B1629PRNDL Reverse Input Short to BatteryVehicle Security ModuleREFER to INSTRUMENT CLUSTER .
B1869Lamp Air Bag Warning Indicator Circuit OpenRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1870Lamp Air Bag Warning Indicator Circuit Short to BatteryRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1877Seatbelt Driver Pretensioner Circuit OpenRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1878Seatbelt Driver Pretensioner Circuit Short to BatteryRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1879Seatbelt Driver Pretensioner Circuit Short to GroundRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1881Seatbelt Passenger Pretensioner Circuit OpenRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1882Seatbelt Passenger Pretensioner Circuit Short to BatteryRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1883Seatbelt Passenger Pretensioner Circuit Short to GroundRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1885Seatbelt Driver Pretensioner Circuit Resistance Low on SquibRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1886Seatbelt Passenger Pretensioner Circuit Resistance Low on SquibRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1891Air Bag Tone Warning Indicator Circuit Short to BatteryRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1892Air Bag Tone Warning Indicator Circuit FailureRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1916Air Bag Driver Circuit Short to BatteryRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1921Air Bag Diagnostic Monitor Ground Circuit OpenRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1925Air Bag Passenger Circuit Short to BatteryRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1932Air Bag Driver Circuit OpenRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1933Air Bag Passenger Circuit OpenRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1934Air Bag Driver Inflator Circuit Resistance Low on SquibRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1935Air Bag Passenger Inflator Circuit Resistance Low on SquibRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1936Air Bag Driver Circuit Short to GroundRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1938Air Bag Passenger Circuit Short to GroundRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2143NVM Memory FailureInstrument ClusterREFER to INSTRUMENT CLUSTER .
B2226Front Crash Sensor Internal FaultRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2227Front Crash Sensor Communications FaultRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2276Less Than Two Transmitters ProgrammedVehicle Security ModuleREFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2425Remote Keyless Entry Out of SyncVehicle Security ModuleREFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2477Module Configuration FailureInstrument ClusterREFER to INSTRUMENT CLUSTER .
B2477Module Configuration FailureVehicle Security ModuleREFER to MODULE CONFIGURATION .
B2658Wait to Start Indicator Circuit OpenInstrument ClusterREFER to INSTRUMENT CLUSTER .
B2792Cross Link Between Firing LoopsRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2982Park Brake Switch Input Circuit OpenInstrument ClusterREFER to INSTRUMENT CLUSTER .
C1095ABS Hydraulic Pump Motor Circuit FailureABS ModuleREFER to ANTI-LOCK CONTROL .
C1096ABS Hydraulic Pump Motor Circuit OpenABS ModuleREFER to ANTI-LOCK CONTROL .
C1145Speed Wheel Sensor RF Input Circuit FailureABS ModuleREFER to ANTI-LOCK CONTROL .
C1148Speed Wheel Sensor RF Coherency FaultABS ModuleREFER to ANTI-LOCK CONTROL .
C1155Speed Wheel Sensor LF Input Circuit FailureABS ModuleREFER to ANTI-LOCK CONTROL .
C1158Speed Wheel Sensor LF Coherency FaultABS ModuleREFER to ANTI-LOCK CONTROL .
C1169ABS Fluid Dumping Exceeds Maximum TimingABS ModuleREFER to ANTI-LOCK CONTROL .
C1184ABS System Is Not OperationalABS ModuleREFER to ANTI-LOCK CONTROL .
C1185ABS Power Relay Output Circuit FailureABS ModuleREFER to ANTI-LOCK CONTROL .
C1194ABS Outlet Valve Coil LF Circuit FailureABS ModuleREFER to ANTI-LOCK CONTROL .
C1196ABS Output Valve Coil LF Circuit Short to BatteryABS ModuleREFER to ANTI-LOCK CONTROL .
C1198ABS Inlet Valve Coil LF Circuit FailureABS ModuleREFER to ANTI-LOCK CONTROL .
C1200ABS Inlet Valve Coil LF Circuit Short to BatteryABS ModuleREFER to ANTI-LOCK CONTROL .
C1202ABS Outlet Valve Coil Rear Circuit FailureABS ModuleREFER to ANTI-LOCK CONTROL .
C1204ABS Output Valve Coil Rear Circuit Short to BatteryABS ModuleREFER to ANTI-LOCK CONTROL .
C1206ABS Inlet Valve Coil Rear Circuit FailureABS ModuleREFER to ANTI-LOCK CONTROL .
C1208ABS Inlet Valve Coil Rear Circuit Short to BatteryABS ModuleREFER to ANTI-LOCK CONTROL .
C1210ABS Outlet Valve Coil RF Circuit FailureABS ModuleREFER to ANTI-LOCK CONTROL .
C1212ABS Output Valve Coil RF Circuit Short to BatteryABS ModuleREFER to ANTI-LOCK CONTROL .
C1214ABS Inlet Valve Coil RF Circuit FailureABS ModuleREFER to ANTI-LOCK CONTROL .
C1216ABS Inlet Valve Coil RF Circuit Short to BatteryABS ModuleREFER to ANTI-LOCK CONTROL .
C1220Lamp ABS Warning Output Circuit Short to BatteryABS ModuleREFER to ANTI-LOCK CONTROL .
C1222Speed Wheel MismatchABS ModuleREFER to ANTI-LOCK CONTROL .
C1225Lamp Brake Warning Output Circuit Short to BatteryABS ModuleREFER to ANTI-LOCK CONTROL .
C1226Lamp Brake Warning Output Circuit Short to GroundABS ModuleREFER to ANTI-LOCK CONTROL .
C1229Speed Wheel Sensor Rear Center Coherency FaultABS ModuleREFER to ANTI-LOCK CONTROL .
C1230Speed Wheel Sensor Rear Center Input Circuit FailureABS ModuleREFER to ANTI-LOCK CONTROL .
C1233Speed Wheel LF Input Signal MissingABS ModuleREFER to ANTI-LOCK CONTROL .
C1234Speed Wheel RF Input Signal MissingABS ModuleREFER to ANTI-LOCK CONTROL .
C1237Speed Wheel Rear Input Signal MissingABS ModuleREFER to ANTI-LOCK CONTROL .
C1284Oil Pressure Switch FailureInstrument ClusterREFER to INSTRUMENT CLUSTER .
C1414Incorrect Module Design LevelRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM .
P1139Water in Fuel Indicator CircuitInstrument ClusterREFER to INSTRUMENT CLUSTER .
U0002High Speed CAN Communication BUS PerformanceInstrument ClusterREFER to MODULE COMMUNICATIONS NETWORK .
U1900CAN Communication BUS Fault-Receive ErrorInstrument ClusterREFER to MODULE CONFIGURATION .
U2023Fault Received From External NodeInstrument ClusterREFER to MODULE CONFIGURATION .

Diagnostic Trouble Code (DTC) Chart

Inspection and Verification

  1. Verify the customer concern.
  2. Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Central junction box (CJB) fuse(s): 2 (10A) 23 (20A) Loose or corroded connector(s) Vehicle security module
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the cause is not visually evident, connect the diagnostic tool to the data link connector (DLC) and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
  5. If the diagnostic tool still does not communicate with the vehicle, refer to diagnostic tool operating manual.
  6. Carry out the diagnostic tool data link test. If the diagnostic tool responds with: CAN, ISO circuits fault; all electronic control units no response/not equipped, refer to «MODULE COMMUNICATIONS NETWORK»(ref-231405) . No response/not equipped for the vehicle security module, GO to «PINPOINT TEST A»(ref-231414-S36712561842006050800000) . System passed, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs, and carry out the self-test diagnostics for the vehicle security module.
  7. If the DTCs retrieved are related to the concern, go to the «DIAGNOSTIC TROUBLE CODE CHART»(ref-231414-S03857825512006050800000) .
  8. If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(ref-231414-S20996846612006050800000) .

Symptom Chart

ConditionPossible SourcesAction
No communication with the vehicle security moduleCentral junction box (CJB) fuse(s): 2 (10A) 23 (20A) Circuitry Vehicle security moduleGO to PINPOINT TEST A .

MULTIFUNCTION ELECTRONIC MODULES SYMPTOM CHART

Scheme 19

Scheme 19: PINPOINT TEST A: NO COMMUNICATION WITH THE VEHICLE SECURITY MODULE

Scheme 20

Scheme 20
  1. A1 CHECK THE VOLTAGE TO THE VEHICLE SECURITY MODULE Key in OFF position. Disconnect: Vehicle Security Module C203a. Disconnect: Vehicle Security Module C203b. Key in ON position. Measure the voltage between the vehicle security module C203a-12, circuit 517 (BK/WH), harness side and ground; and between the vehicle security module C203b-25, circuit 640 (RD/YE), harness side and ground. Are the voltages greater than 10 volts? Yes : GO to A2. No : REPAIR the circuit(s) in question. CLEAR the DTCs. REPEAT the self-test.
  2. A2 CHECK THE GROUND CIRCUITS FOR AN OPEN Key in OFF position. Measure the resistance between the vehicle security module C203a-13, circuit 1205 (BK), harness side and ground; and between the vehicle security module C203b-14, circuit 57 (BK), harness side and ground. Are the resistances less than 5 ohms? Yes : REFER to «MODULE COMMUNICATIONS NETWORK»(ref-231405) to continue communication diagnostics. No : REPAIR the circuit(s) in question. CLEAR the DTCs. REPEAT the self-test.

Scheme 21

Scheme 21: Removal

Scheme 22

Scheme 22
  1. Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-231356) .
  2. Remove the RH A-pillar lower trim panel.
  3. Remove the vehicle security module. Disconnect the electrical connectors. Remove the nuts.
